WIRING (C14 & C16)
CARBON
BRUSH
CARBON
BRUSH
MOTOR
AC
SWITCH
1
2
1
2
ELECTRONICS
UNIT
Temperature Sensor
* C14 With Protective earth
* C16 Without Protective earth
