Parts List DM14
NO. Parts Name Q'TY
1 POWER SUPPLY CABLE 1
2 PRCD INTERRUPTER PROTECTION 220V 1
3 CORD ARMOR 1
4 EXTERNAL STAR WASHER M4 1
5 PANHEAD MACHINE SCREW M4 x 10 1
6~7 N/A -
8 SWITCH 1
9 N/A -
10 PANHEAD TAPPING SCREW M4 x 25 4
11 COVER (220V) 1
12 PANHEAD MACHINE SCREW M4 x 12 6
13 ELECTRONICS UNIT 1
14 SOCKET CAP SCREW M5 x 25 6
15 FLAT WASHER Ø5 x Ø12 x 1 2
16 TOP HANDLE 1
17 MOTOR END CASTING 1
18 BRUSH SPRING 2
19 NYLOCK NUT M5 x 8 2
20 PANHEAD MACHINE SCREW M4 x 6 2
21 CARBON BRUSH 7x17x19 2
22 BRUSH HOLDER PLATE ASSY. 1
23 MOTOR HOUSING 1
24 SOCKET CAP SCREW M6 x 75 4
25 MOTOR INSULATION SLEEVE 1
26 STATOR 1
27 PANHEAD MACHINE SCREW M5 x 110 2
28 FAN SHROUD 1
29 BALL BEARING 6200-LLU 1
30 ARMATURE M1.25 x 7T 1
31 BALL BEARING 6202-2NSE 1
32 OIL SEAL Ø14 x Ø25 x 7 1
33 GEAR PLATE 1
34 GASKET 1
35 NEEDLE BEARING TLA 0810 1
36 CLUTCH NUT M12 x P1.75 x 9 1
37 N/A -
38 PRESSURE DISC Ø16 x Ø34.8 x 2.5 2
39~40 N/A -
41 INPUT GEAR M1.25 x 44T 1
42 BUSHING Ø15.9 x Ø22 x 4.9 1
43 INPUT SHAFT M1.75 x 13T ; M1.5 x 12T 1
44 BALL BEARING 6200 ZZ 2
45 NEEDLE BEARING TLA 1010 1
46 INTERNAL CIRCLIP IS-18 2
47 SLIDER GEAR-CD M1.75 x 36T 1
48 LAY GEAR M1.5 x 46T 1
49 COUNTERSHAFT GEAR M2.0 x 26T 1
50 PARALLEL KEY 5 x 5 x 25 1
51 PARALLEL KEY 6 x 6 x 15 1
NO. Parts Name Q'TY
52 N/A -
53 N/A -
54 NEEDLE BEARING TA1815 1
55 INTERNAL CIRCLIP IS-25 2
56 SLIDER GEAR-AB M2.0 x 28T 1
57 OUTPUT GEAR M2.0 x 40T 1
58 CLUTCH NUT M27 x P1.0 x 7.8 1
59 THRUST BEARING Ø30 x Ø47 x 2 1
60 N/A -
61 GEAR HOUSING 1
62 SOCKET CAP SCREW M5 x 12 2
63~66 N/A -
67 O-RING Ø3 x Ø20 x Ø26 2
68 N/A -
69 NEEDLE BEARING TAF304020 1
70 THRUST BEARING 51106 1
71 OIL SEAL Ø40 x Ø50 x 7 1
72 WATER FEED COLLAR 1
73 WATER FEED CONNECTOR KIT 1
74 N/A -
75 SOCKET CAP SCREW M5 x 40 3
76 OIL SEAL Ø40 x Ø52 x 7 2
77 N/A -
78 DOWEL PIN Ø4 x 11.8 2
79 ANTI-SEIZE CUP 1
80 O-RING Ø1.5 x Ø32 x Ø35 2
81 THRUST RING Ø32 x Ø52 x 1 1
82 ANTI-SEIZE RING 1
83 O-RING Ø1.5 x Ø49 x Ø52 1
84~87 N/A -
88 TERMINAL CONNECTOR BLOCK PA-10-H 24A 2
89~93 N/A -
94 CLUTCH DISC SET 1
95 GASKET 1
96 SWITCH BOOT 1
97 GEAR SELECTOR 2
98 SPRING Ø0.6 x Ø3.8 x Ø5 x 11T x 35L 2
99 RELEASE PIN 2
100 COUNTERSHAFT SET 1
101 N/A -
102 BULLS-EYE LEVEL 1
103 SELECTOR DISC 1
104 SELECTOR DISC 1
105 LED OVERLOAD LAMP Ø10 110V&220V 1
106 LAMP COVER 1
107 SPINDLE SET 1-1/4"-7 x 1/2"BSP-300.5MM 1
108 STAINLESS BUSHING Ø38xØ40x41 1
A1 EXTENSION SPACER 1
GEAR OIL 625cc 1
