AGP DM10 - Page 17

17
GB
Parts List DM12
NO. Parts Name Q'TY
1 POWER SUPPLY CABLE 1
2 PRCD INTERRUPTER PROTECTION 220V 1
3 CORD ARMOR 1
4 EXTERNAL STAR WASHER M4 1
5 PANHEAD MACHINE SCREW M4 x 10 1
6 N/A -
7 N/A -
8 SWITCH 1
9 N/A -
10 PANHEAD TAPPING SCREW M4 x 25 4
11 COVER (220V) 1
12 PANHEAD MACHINE SCREW M4 x 12 6
13 ELECTRONICS UNIT 1
14 SOCKET CAP SCREW M5 x 25 6
15 FLAT WASHER Ø5 x Ø12 x 1 2
16 TOP HANDLE Ø5 1
17 MOTOR END CASTING 1
18 BRUSH SPRING 2
19 NYLOCK NUT M5 x 8 2
20 PANHEAD MACHINE SCREW M4 x 6 2
21 CARBON BRUSH 7x17x19 2
22 BRUSH HOLDER PLATE ASSY. 1
23 MOTOR HOUSING 1
24 SOCKET CAP SCREW M6 x 75 4
25 MOTOR INSULATION SLEEVE 1
26 STATOR 1
27 PANHEAD MACHINE SCREW M5 x 110 2
28 FAN SHROUD 1
29 BALL BEARING 6200-LLU 1
30 ARMATURE M1.25 x 7T 1
31 BALL BEARING 6202-2NSE 1
32 OIL SEAL Ø14 x Ø25 x 7 1
33 GEAR PLATE 1
34 GASKET 1
35 NEEDLE BEARING TLA 0810 1
36 CLUTCH NUT M12 x 9 1
37 N/A -
38 PRESSURE DISC Ø16 x Ø34.8 x 2.5 2
39~40 N/A -
41 INPUT GEAR M1.25 x 44T 1
42 BUSHING Ø15.9 x Ø22 x 4.9 1
43 INPUT SHAFT M1.5 x 27T x 20T x 13T 1
44 BALL BEARING 6200 ZZ 2
45 NEEDLE BEARING TLA 1010 1
46 INTERNAL CIRCLIP IS-14 1
47 COUNTERSHAFT SET 1
48 SPINDLE GEAR M1.5 x 38T 1
49 INTERNAL CIRCLIP IS-18 2
50 LAY GEAR M1.5 x 45T 1
NO. Parts Name Q'TY
51 PARALLEL KEY 5 x 5 x 40 1
52 N/A -
53 N/A -
54 NEEDLE BEARING TA1815 1
55 NYLOOK NUT M20 x P1.5 1
56 OUTPUT GEAR M2.0 x 41T 1
57 THRUST BEARING Ø30 x Ø47 x 2 1
58 N/A -
59 GEAR HOUSING 1
60 SOCKET CAP SCREW M5 x 12 1
61~62 N/A -
63 O-RING Ø3 x Ø20 x Ø26 1
64 N/A -
65 NEEDLE BEARING TAF304020 1
66 THRUST BEARING 51106 1
67 OIL SEAL Ø40 x Ø50 x 7 1
68 WATER FEED COLLAR 1
69 WATER FEED CONNECTOR KIT 1
70 N/A -
71 SOCKET CAP SCREW M5 x 40 3
72 OIL SEAL Ø40 x Ø52 x 7 2
73 N/A -
74 PARALLEL KEY 6 x 6 x 25 1
75 DOWEL PIN Ø4 x 11.8 2
76 ANTI-SEIZE CUP 1
77 O-RING Ø1.5 x Ø32 x Ø35 2
78 THRUST RING Ø32 x Ø52 x 1 1
79 ANTI-SEIZE RING 1
80 O-RING Ø1.5 x Ø49 x Ø52 1
81 TERMINAL CONNECTOR BLOCK PA-12-H 2
82~86 N/A -
87 CLUTCH DISC SET 1
88 PARALLEL KEY 4 x 4 x 30 1
89 OIL IMPELLER 1
90 GASKET 1
91 SWITCH BOOT 1
92 GEAR SELECTOR 1
93 SPRING Ø0.6 x Ø3.8 x Ø5 x 11T x 35L 1
94 RELEASE PIN 1
95 COUNTERSHAFT SET 1
96 BULLS-EYE LEVEL 1
97 SELECTOR DISC 1
98 LED OVERLOAD LAMP Ø10(110V&220V) 1
99 LAMP COVER 1
100 SPINDLE 1-1/4"-7xPS1/2"-296.5MM 1
101 STAINLESS BUSHING Ø38xØ40x41 1
A1 EXTENSION SPACER 1
GEAR OIL SHELL SPIRAX A80/90 625cc 1
