TECHNICAL DATA
Model DM14 DM12 DM10 DM9
Voltage / Power 220-240V~ 50-60Hz :16A/3500W or 110-120V~ 50-60Hz : 25A /2800W (see nameplate)
No Load Speeds min
-1
385 / 530 / 975 / 1340 350 / 600 / 1000 450 / 810 / 1300 550 / 1000 / 1600
Rated Load Speeds min
-1
225/ 300 / 565 / 780 220 / 370 / 620 270 / 480 / 780 345 / 630 / 1000
Drilling Capacity Ø400mm (16") Ø350mm (14") Ø300mm (12") Ø250mm (10")
Dimensions 550mm x 155mm x 210mm
Gear Oil Type 90W
Gear Oil Capacity 625ml
Spindle Thread 1-1/4" UNC male, 1/2" BSP female
Protection Class Class 1 With RCD
Weight 13.5kg 12.9kg 12.9kg 12.9kg
DM14
DM12
3.
1.
2.
4.
9.
5.
7.
8.
230V models
8.
110V models
6.
10.
DM10
DM9
1. Spindle
2. Gear Box
3. Gear Selector(s)
4. Motor Unit
5. Tail Handle
6. Bull's Eye Level
7. Tubular Spirit Level
8. On/O Switch
9. Water Feed Valve
10. Anti-Sieze Ring
11. LED Indicator Light
(Load & Temperature)
11.
11.
