AGP DM52D - Page 3

3
D-Handle Model
Release Button
Gear Selector
Lock Screw
Tubular Spirit Level
Motor
Main Handle
Power Supply
Cable
Spindle
Side Handle
Lock Button
Trigger Switch
DM52P,52D
Percussion Selector
Hammer
(percussion
ON)
Wet mode (optional) Dust aspiration mode (optional)
Port
Water Feed Valve
Coupling
Vacuum
Adaptor Head
Water Feed
Adaptor Head
Percussion
Selector
(optional)
TECHNICAL DATA
No Hammer
(percussion
OFF)
Model D-Handle Model
Power Input 1800W
Voltage 110-120V~ 50-60Hz, 220-240V~ 50-60Hz
No Load /Full Load min
-1
Speed 1 1800 / 1080
Speed 2 3600 / 2160
Percussion Frequency Speed 1 29,000 bpm
(optional) Speed 2 56,000 bpm
Arbor Thread 1-1/4-7 UNC male x 1/2" BSP female or M18-2.5 or 1/2" BSP (Specify when ordering)
Capacity 120mm
Dimensions 505 x 105 x 210
Neck Diameter 60mm
Net Weight 5.2 kg
