附录
Appendixes
变速箱中间轴后端
R
ea
r
ends of gearbox countershaft
单列向心球轴承
Single-row radial ball bearing

6211

1

GB/T 276
变速箱中间轴前端
F
ront ends of gearbox countershaft
单列向心球轴承
Single-row radial ball bearing

6210N

1

GB/T 276
分动箱中间齿轮轴
Inte
r
meidate gear shaft of transfer case
圆柱滚子轴承
Cylindrical roller bearing

42305E

2

GB/T 283
分动箱传动轴后端
R
ea
r
end of the drive shaft of transfer
case
单列向心球轴承
Single-row radial ball bearing

6306E

2

GB/T 276
前驱动传动轴中段
Inte
r
meidate section of the front drive
shaft
单列向心球轴承
Single-row radial ball bearing

6006E

1

GB/T 276
前驱动小锥齿轮轴后端
R
ea
r
end of the small bevel gear shaft of
front drive
圆锥滚子轴承
Tappered roller bearing

32207

1
特制
special
前驱动小锥齿轮轴前端
F
ront end of the small bevel gear shaft
o
f
front drive
圆锥滚子轴承
Tappered roller bearing

802048

1
特制
special
前驱动差速器
D
ifferential of front drive
圆锥滚子轴承
Tappered roller bearing

2007112E

2

GB/T 297
前驱动轴中段
Intermediate section of the front drive
shaft
单列向心球轴承
Single-row radial ball bearing

6007

2

GB/T 297
前轮毂轴承
B
earing for the front wheel hub
圆锥滚子轴承
Tappered roller bearing

819310

4

special
前最终传动行星齿轮轴
P
lanetar
y
gear shaft of the front final
drive
滚针
R
olling needle

5x23.8


GB/T 309
转向节轴内侧
Inner flank of the steering knuckle
圆锥滚子轴承
Tappered roller bearing

32209

2

GB/T 297
转向节外侧
Outer flank of the steering knuckle
圆锥滚子轴承
Tappered roller bearing

32307

2

GB/T 297
转向节主销
K
ingpin of the steering knuckle
平底推力球轴承
Thrust ball bearing with flat seat

51210

2
G

B/T 301
副离合轴承座
B
earing block for the auxiliary cluthc
shaft
角接触球轴承
A
ugular contact ball bearing

7016AC

1
G

B/T 292
主离合分离轴承座
B
earing block for the release shaft of
m
ain clutch
角接触球轴承
A
ugular contact ball bearing

996712

1
特制
Hand
tailor
转向器立柱套管轴承座
B
earing block for the sleeve of steering
column
单列向心球轴承
Single-row radial ball bearing

6004

1
G

B/T 276
