操作说明
Operator Instruction
雨刮开关
Wiper Switch
“2”位，雨刮器快档工作；“1”位，雨刮慢档工作：“0”位，雨刮器复位停止工作。
Position "2"- quick operating; Position"1"- slow operating; Position"0"- resetting, stop
operating.
顶、后灯开关
Top and rear light switch
“0”位：切断电源。“l”位：顶工作灯亮(有驾驶室时使用)。“2”位：后工作灯亮。
Power off Top lamp lit (if with cab) Position “2": rear lights on.
灯光开关
Light switch
“0”位时切断电源。“1”位：示廓位置灯亮。“2”位：控制前照灯电源，接通此位，
即可用变光开关控制前照灯远近光转换。
Shutoff the power. Outline marker lamp (position lamp) lit Control front light power
supply, dimmer switch is used to control front light far/near light switchover as long as
this position is powered on
变光开关
Dip switch
“2”位：远光灯亮。“0”位：近光灯亮。“l”位：备用。远近光转换受灯光开关控制。
Headlight on full beam is lit Dipped headlight lit. Position “1". stand by service.
Conversion between the high beam and dipped headlight is controlled by light switch
左侧翘板开关组合
Left rocker switch combination
1．变光开关
Dimmer switch
2．灯光开关
Light switch
3．顶、后工作灯开关
Roof/rear light switches
4．雨刮器开关
Rain brush switch
图 4-6 左侧翘板开关组合
Fig. 4-6left rocker switch
预热指示灯(黄色)
Preheating indictor (yellow)
拖拉机预热时，该灯亮。
When the tractor is preheating, the lamp will be lit.
