1
Turbocharged Diesel Engine
Model No.
YN27GBZ
YN27GBZ1
YN27GBZ2
YN30GBZ
YN30GBZ1
Model
in-line four-cylinder, direct injection, water cooling, four-stroke, turbocharged
Bore×Stroke（mm） 90×105 95×105
Total Piston Displacement L
2.7
3.0
Rated Power/Speed
kW/r/min
60/2400 50/2600
52/2600
60/2600 60/2400 50/2600 62/2400 62/2600 65/2600 68/2600
Max.NetPower/Speed
kW/r/min
57/2400 47/2600
49/2600
57/2600 57/2400 47/2600 60/2400 60/2600 62/2600 65/2600
Max. Torque/Speed
N·m/r/min
213-237/1800-2200 230-255/1600-1800
Cylinders Working Sequence
1-3-4-2
Min.Idling Stabilized Speed
800 ±20
Min. Fuel Consumption Rate
（
g/Kw.h
）
≤ 225
Crankshaft Rotating Direction
Clockwise (from the front view of diesel engine)
Lubricating Way
Pressure & splash combined
Cooling Way
Forced circulating water cooled
