Agrison TX930LX - Page 20

1
Model No.
YN38GBZ
YN38GBZ1
YN38GBZ2
Model
in-line four-cylinder, direct injection, water cooling, four-stroke, turbocharged
Bore×Stroke（mm） 102×115
Total Piston Displacement L
3.8
Rated Power/Speed
kW/r/min
63/2600 58/2400 65/2400 75/2400
Max.NetPower/Speed
kW/r/min
60/2600 55/2400 61/2400 71/2400
Max. Torque/Speed
N·m/r/min
260-360/1800-2200
Cylinders Working Sequence
1-3-4-2
Min.Idling Stabilized Speed
(r/min)
800 ±20
Min. Fuel Consumption Rate
（
g/Kw.h
）
≤ 225
Crankshaft Rotating Direction
Clockwise (from the front view of diesel engine)
Lubricating Way
Pressure & splash combined
Cooling Way
Forced circulating water cooled
