Owner’s Manual
Manual Version 1.1
I. Functions
A. Top Panel:
BLEND: Controls the mix ratio between clean and modulated signal.
The most dramatic chorusing effect is achieved when the knob is set to the 12:00
position (50:50 ratio).
When this knob is fully counterclockwise the mix ratio is 90:10 in favor of clean
signal. When this knob is fully clockwise the mix ratio is reversed and favors the
modulated signal 10:90.
RATE: Controls the speed of modulation.
INTENSITY: Controls the intensity of the modulation. Higher intensity produces
more dramatic chorusing effect.
WIDTH: Sets the range for the INTENSITY to work within. Turning WIDTH
clockwise will broaden the range, allowing more intense effect.
ENGAGE: Toggles between on and off. The blue LED indicates that the effect is on.
B. Side Panel:
IN: ¼” input
DC IN: This is a standard 2.1mm DC jack. The center terminal polarity is negative.
OUT: ¼” output
• For mono output use a standard ¼” cable to your amplifier.
• For stereo operation with two amplifiers use a ¼” Y adapter cable
with one ¼” TRS plug to two ¼” TS jacks.
