Owner’s Manual
Manual Version 1.0
I. Functions
A. Top Panel Controls:
LEVEL: Controls the volume of the output. Used for setting loudness and make-up
gain.
THRESHOLD: Sets the input level at which compression begins. Turning the knob
clockwise causes compression to begin at lower input levels.
ATTACK: Sets the amount of time before compression begins after a note is played.
Turning the knob clockwise causes the attack time to become longer, allowing the
leading edge of the note to be heard without compression.
SLOPE: Controls the compression ratio, or slope. As you turn the knob clockwise the
dynamic range is compressed more.
ENGAGE: Toggles between on and off. The blue LED indicates that the effect is on.
B. Side Panel Connections:
IN: ¼” input
DC IN: This is a standard 2.1mm DC jack. The center terminal polarity is negative.
OUT: ¼” output
C. Specifications:
Current consumption…………………………...5mA ECIFIC
Noise Level: ...................................................-95 dBu ‘A’ weighted *
Input impedance: ................................................1MΩ (Effect On)
Output impedance: ............................................. 1 KΩ
Distortion: ……………………………………..< 0.2% *+
Maximum Output:……. ………………………. +6dBu (1.6VRMS)
Battery Life…………………..: …………….…~150hours
External DC Power:………………………….…9-10VDC, 20mA min, center
terminal negative
* = all knobs set to 12 o'clock
+ = nominal input of -20dBu
