GO-AROUND MODE
CAUTION
When operating in GO-AROUND mode, use caution to avoid
exceeding engine power limits when satisfying the collective
command bar.
Missed approach - attitude hold mode
Apply power to approximately maximum continuous power.
For approach speeds below 80 KIAS no initial pitch-up attitude adjustment is
required. Re-center HELIPILOT indicators with FTR button.
Approach angle vs airspeed and rate of descent (Sea level - ISA)
Kts
IAS
(CAS)
R/D
Ft/min
60
(67)
70
(74)
80
(81)
100
(100)
120
(116)
500 4.2 3.8 3.5 2.8 2.4
750 6.3 5.7 5.2 4.2 3.7
1000 8.4 7.6 7.0 5.6 4.9
NOTE
The steepest demonstrated approach slope is 8.4 degrees.
APPROACH AND LANDING
RPM switch : Set 102%.
NOTE
RPM shall be set to 102% during take-off and landing in the
airspeed range from 0 knot to 60 knots and in hovering conditions.
RFM A109E
2-42 R.A.I. Approved
Rev. 11
