GROSS WEIGHT
2450 kg
( 5401 lb )
-12 -10 -8 -6 -4 -2 0 2 4 6 8 10 12 14 16 18 20
-1
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
RATE OF CLIMB - FEET/MINUTE X 100
PRESSURE ALTITUDE - FEET X 1000
-4 -2 0 2 4 6 8
RATE OF CLIMB - METERS/SECOND
0
5
10
15
20
25
30
35
40
45
50
55
60
PRESSURE ALTITUDE - METERS X 100
-30
-20
-10
0
10
20
30
40
OAT LIMIT
ISA+30
OAT - ˚C
RATE OF CLIMB ONE ENGINE INOPERATIVE
MAXIMUM CONTINUOUS POWER
ROTOR: 100 %
60 kts IAS
ELECTRICAL LOAD: 150 A TOTAL
TR 109-60-114/II REV C ABHD102B
Figure 4-21. Rate of climb - OEI - maximum continuous power - 2450 kg.
RFM A109E
4-30 R.A.I. Approved
Rev. 23
