LIST OF ILLUSTRATIONS
Page
Figure 4-1. Height-Velocity diagram - basic with ECS ON. 10 of 23
Figure 4-2.
Height-Velocity diagram - EAPS OFF with ECS ON.
11 of 23
Figure 4-3.
Height-Velocity diagram - EAPS ON with ECS ON.
12 of 23
Figure 4-4. Height-Velocity diagram - Chart B. 13 of 23
Figure 4-5. Hovering ceiling - IGE - take-off power. 14 of 23
Figure 4-6. Hovering ceiling - IGE - maximum continuous
power. 15 of 23
Figure 4-7. Hovering ceiling - OGE - take-off power. 16 of 23
Figure 4-8. Hovering ceiling - OGE - maximum continuous
power. 17 of 23
Figure 4-9. Rate of climb - all engines - take-off power -
2050 kg. 18 of 23
Figure 4-10. Rate of climb - all engines - take-off power -
2450 kg. 19 of 23
Figure 4-11. Rate of climb - all engines - take-off power -
2850 kg. 20 of 23
Figure 4-12. Rate of climb - all engines - maximum con-
tinuous power - 2050 kg. 21 of 23
Figure 4-13. Rate of climb - all engines - maximum con-
tinuous power - 2450 kg. 22 of 23
Figure 4-14. Rate of climb - all engines - maximum con-
tinuous power - 2850 kg. 23 of 23
RFM A109E
APPENDIX 5
E.A.S.A. Approved Page 3 of 23
Rev. 44
