AGUSTA A109E - Page 369

GROSS WEIGHT
2450 kg
( 5401 lb )
0 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32
-1
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
RATE OF CLIMB - FEET/MINUTE X 100
PRESSURE ALTITUDE - FEET X 1000
2 4 6 8 10 12 14 16
RATE OF CLIMB - METERS/SECOND
0
5
10
15
20
25
30
35
40
45
50
55
60
PRESSURE ALTITUDE - METERS X 100
-30 -20 -10
10
20
OAT - ˚C
RATE OF CLIMB ALL ENGINES
MAXIMUM CONTINUOUS POWER
ROTOR: 100 %
HEATER ON
60 kts IAS
ELECTRICAL LOAD: 150 A TOTAL
TR 109-60-114/II REV C ABHD106B
0
OAT LIMIT ISA+30
Figure 4-9. Rate of climb - all engines - maximum continuous power - 2450 kg.
RFM A109E
APPENDIX 6
R.A.I. Approved Page 17 of 18
Rev. 23
UNMAINTAINED COPY
