Aideepen TC-T7-H User Manual

Email:sales@aideepen.com
8 / 8
Current) ②
Double Diodes
Forward Voltage
Zener Diode
0.01-4.50V
(Transistor test area)
Forward Voltage, Reverse Voltage
0.01-20V
(Zener Diode test area)
Reverse Voltage
MOSFET
JFET
Cg(Gate Capacitance), Id(Drain Current) at
Vgs(Gate to Source Threshold Voltag), Uf(Forward
Voltage of protecting diode) ④
IGBT
Id(Drain Current) at Vgs(Gate to Source Threshold
Voltag), Uf(Forward Voltage of protecting diode) ④
MOSFET
Vt(Gate to Source Threshold Voltag), Cg(Gate
Capacitance), Rds(Drain to Source On Resistance),
Uf(Forward Voltage of protecting diode) ④
Thyristor
Igt(Gate trigger
current )<6mA
Gate trigger voltage
Triac
Capacitor
25pF-100mF
Capacitance, ESR(Equivalent Series Resistance),
Vloss ①
Resistor
0.01-50MΩ
Resistance
Inductor
0.01mH-20H
Inductance, DC Resistance ⑤
Battery
0.1-4.5V
Voltage, Battery Polarity
Note①: Iceo, Ices, Uf displayed only when effective
Note②: Diode Capacitance, Ir(Reverse Current) displayed only when effective
Note③: Displayed only when has protecting diode
Note④: ESR, Vloss displayed only when effective
Note⑤: Measurement of inductors with resistance below 2100Ω
4 FAQ
Question
Cause
Solution
Cannot power on
Built-in Li-ion Battery
is dead
Charging the Li-ion Battery, charging methods
see section 2.9
Inaccurate
measurements
Inaccurate calibration
parameters
Please re-calibration, see section 2.4
5 Packing List
Tester x1,
Debug accessories x1.
USB charging line x1

Aideepen TC-T7-H Specifications

General

Brand	Aideepen
Model	TC-T7-H
Category	Test Equipment
Language	English
