19
Z1
A input 1MΩ input impedance.
Z5
A input 50
Ω
input impedance.
A1
A input 1:1 attenuator.
A5
A input 5:1 attenuator.
ER
Rising edge (A Input only).
EF
Falling edge (A Input only).
FI
Filter In (A Input only).
TF830
FO
Filter Out (A Input only).
TF830
L
Low frequency mode.
TF830
TT <nr1>
Trigger threshold set to nnnn mV (-300 to +2100mV).
DC coupling.
TO <nr1>
Trigger auto (average), offset by nn mV (-60 to +60mV).
AC coupling.
Values assume 1:1 attenuator; for 5:1 attenuation thresholds will be set value x5.
TO?
Returns current TO Threshold setting in mV
TT?
Returns current TT Threshold setting in mV
TA
Trigger auto (average, without offset). Set DC coupling first.
TC
Trigger centre.
TF830
TP
Trigger positive.
TF830
TN
Trigger negative.
TF830
M1
Measurement time 0.3s.
TF830
M2
Measurement time 1s.
TF830
M3
Measurement time 10s.
TF830
M4
Measurement time 100s.
E?
Every result query.
TF830
C?
Continuous result query.
N?
Next result query.
TF830
?
Current result query.
TF830
STOP
Stops further measurement results being sent.
I?
Identifier query. Returns model number only.
TF830
*IDN?
Instrument identification. Returns full instrument identification.
R
Reset measurement.
TF830
*RST
Reset instrument to default settings.
S?
Status query.
TF830
LOCAL
Returns instrument to local operation.
UD <data>
Store user data.
UD?
Returns <data>.
