2 OPERATION
WARNING: Ensure the weapon is not loaded and the safety selector is in the ”safe”
position before attempting to install, remove or perform maintenance.
2.1 Install battery
a Remove the front ip-up lens cover by pushing on the hinge in the direction away
from the sight.
b Loosen and remove the battery cap.
c Insert battery with the positive end (+) toward the sight and the negative end (-)
toward the battery cap as shown in Fig. 1.
CAUTION: Check that the o-ring is in good condition and in position to ensure there
is no water leakage into the battery compartment.
d Tighten the battery cap. As resistance is encountered, continue tightening until the
battery cap will no longer turn.
e Verify that the red dot is visible.
f Re-install the front ip-up lens cover to the sight.
NOTE: For long term storage of the sight, remove the battery.
