2.3 Remove / install ballistic turrets
To remove / install a ballistic turret:
a Set the installed turret to setting ”1” (”A” Fig. 3).
b Push the locking tab in the direction away from the turret.
c While the locking tab is disengaged, remove / install turret.
NOTE: Only remove / install ballistic turrets when the locking tab is pointing to
setting "1" on the ballistic turret (”A” Fig. 3).
CAUTION: ALWAYS perform zeroing if the turret has been changed.
CAUTION: NEVER use the sight without ballistic or wind turret installed.
CAUTION: DO NOT turn the exposed mechanism when the turret has been
removed! ("B" Fig. 3).
