Mechanical Data- W2C0 Continued
SC25D045-W2C0 SC25D050-W2C0 SC25D055-W2C0
Standard Dry Cooler Match 1 x DR55 1 x DR70 1 x DR70
Capacity
Nom Cooling (Gross) – W2 (1) kW 43.8 47.8 54.6
Nom Cooling (Gross) – C0 (2) kW 71.2 74.8 79.8
Total Heat of Rejection – W2 kW 54.5 60.2 68.9
Capacity Steps 2 2 3
Fan Gain (6) kW 2.24 2.65 3.01
Dimensions – W x D x H
Mm 2549 x 890 x 1980 2549 x 890 x 1980 2549 x 890 x 1980
Weight – Machine / Operating
(3) Kg 980 / 1020 1050 / 1090 1050 / 1100
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint – Black Grey (RAL 7021)
Material/Colour Frame: Anodised Aluminium Frame with Black Nylon Corners
Evaporator
Rifled Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages 2/1 2/1 2/1
Cooling Coil – C0
Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling /Dehum Stages 1 (Modulated) / 1
Water Volume l 42.2 42.2 42.2
Water Flow l/s 3.81 4.02 4.32
Pressure Drop FC kPa 57.4 55.2 61.68
Condenser
Stainless steel Brazed Plate
Water Volume l 6.1 9.9 9.9
Water Flow l/s 2.66 2.95 3.38
Pressure Drop Condenser kPa 69.06 29.79 38.50
Dry Cooler
Water Volume L 43.2 55.9 55.9
Flowrate l/s 2.66 2.95 3.38
Pressure Drop kPa 33.7 41.8 58.8
Fan Motor
Backwards Curved, Centrifugal direct drive
Motor Type AC AC AC
Quantity x Motor Size kW 3 x 2.38 3 x 2.38 3 x 2.38
Speed @25Pa / Maximum ESP RPM 1092 / 1364 1220 / 1360 1360 /1360
Maximum ESP Pa 328 188 20
Nominal Airflow m³/s 5.3 5.9 6.5
Compressor – Scroll
Configuration – W2C0 Dual Cool – Circuit 1 Tandem Compressors (Water Cooled) / Circuit 2 Chilled Water
Quantity – W2C0 2 2 2
Oil Charge Volume – W2C0 l 2 x 1.57 2 x 3 2 x 3
Oil Type Polyolvinyl Polyolester
Connections
Water Inlet / Outlet –W2 mm 42 42 42
Water Inlet / Outlet – C0 mm 42 42 42
Condensate Drain Hose mm 22 22 22
Filtration Disposable to BS EN 779-G4
Quantity 4 4 4
OPTIONAL EXTRAS
Hot Gas Reheat -
(4)
Nom Heating (Gross) kW 11.5 12.2 12.2
Electric Heating (Total)
kW 21 21 31.5
Humidifier
Capacity kg/hr 8 8 8
Feed/Drain 3/4" BSPF Braided flexible hose / 19mm hose connection
Condensate Pump
Head m 10.8 10.8 10.8
Flow l/m 5 5 5
Drain 10mm Stainless steel Stub Connection
First upgrade Motor - EC Motor
Backwards Curved, Centrifugal direct drive
Quantity x Motor Size kW 3 x 2.2 3 x 2.2 3 x 2.2
Speed @ 25Pa / Maximum ESP rpm 1074 / 1360 1200 / 1360 1337 / 1360
Maximum ESP Pa 314 188 45
Fan Gain (6) kW 1.4 1.92 2.6
Second upgrade Motor - EC Motor
Backwards Curved, Centrifugal direct drive
Quantity x Motor Size kW 3 x 3.1 3 x 3.1 3 x 3.1
Speed @ 25Pa / Maximum ESP rpm 1095 / 1510 1225 / 1510 1254 / 1510
Maximum ESP Pa 464 337 195
Fan Gain (6) kW 1.4 1.92 2.6
Low Pressure Hot Water
(5) Copper Tube/Aluminium Fin
Capacity Gross kW 32.5 35.7 35.7
Water Flow (Nominal) l/s 0.72 0.79 0.79
Pressure drop kPa 20.2 21.8 21.8
LPHW Connection Sizes mm 22 22 22
(1) Entering air 24°C/45% RH condensing water in / out: 35/40°C
(2) Entering air 24°C/45% RH water 7°C/12°C
(3) Machine weight Includes a refrigerant charge / Operating weight includes calculated water volume
(4) Based on air temperature of 15.5 °C leaving the evaporator coil
(5) Based upon low pressure hot water 82 °C inlet / 71°C outlet. Air on 20°C.
(6) Fan gain based on 25 Pa ESP @ nominal air volume. Fan gain figure will change as airflow and ESP change.
W2C0
