AIREDALE SmartCool D - Page 125

Precision Air Conditioning
SmartCool
TM
– D
Precision Air Conditioning
125
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Cooling Duties – Free cooling
Chilled Water Inlet Temperatures
Model Air On
5 °C /10°C 7°C /12°C 8°C / 14°C 10°C / 16°C 5.5°C/ 14.5°C
Temp (°C) %RH
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
SC19D033-W2F0-0
1 x DR40
22 / 50 68.2 54.8 49.3 44.9 40.2 40.2 31.4 31.4 21.3 21.3
24 / 45 77.8 63.1 61.6 55.9 49.1 49.1 40.9 40.9 48.1 48.1
26 / 40 86.2 71.4 70.0 64.3 57.7 57.7 49.7 49.7 58.1 58.1
SC19D038-W2F0-0
1 x DR55
22 / 50 75.5 61.7 55.1 51.3 45.4 45.4 35.6 35.6 22.2 22.2
24 / 45 86.2 71.1 67.9 63.1 55.3 55.3 46.1 46.1 54.8 54.8
26 / 40 95.5 80.6 74.7 68.8 65.0 65.0 56.0 56.0 65.8 65.8
SC19D045-W2F0-0
1 x DR55
22 / 50 85.0 71.1 62.3 62.3 52.2 52.2 41.2 41.2 50.0 50.0
24 / 45 97.3 81.9 74.4 69.8 63.6 63.6 53.0 53.0 63.5 63.5
26 / 40 108.1 92.9 85.2 80.8 74.7 74.7 64.3 64.3 75.8 75.8
SC19D064-W2F0-0
1 x DR95
22 / 50 85.0 71.1 62.3 62.3 52.2 52.2 41.2 41.2 50.0 50.0
24 / 45 97.3 81.9 74.4 69.8 63.6 63.6 53.0 53.0 63.5 63.5
26 / 40 108.1 92.9 85.2 80.8 74.7 74.7 64.3 64.3 75.8 75.8
SC19D070-W2F0-0
1 x DR95 (EC)
22 / 50 85.0 71.1 62.3 62.3 52.2 52.2 41.2 41.2 50.0 50.0
24 / 45 97.3 81.9 74.4 69.8 63.6 63.6 53.0 53.0 63.5 63.5
26 / 40 108.1 92.9 85.2 80.8 74.7 74.7 64.3 64.3 75.8 75.8
SC19D076-W2F0-0
1 x DR95 (EC)
22 / 50 85.0 71.1 62.3 62.3 52.2 52.2 41.2 41.2 50.0 50.0
24 / 45 97.3 81.9 74.4 69.8 63.6 63.6 53.0 53.0 63.5 63.5
26 / 40 108.1 92.9 85.2 80.8 74.7 74.7 64.3 64.3 75.8 75.8
SC25D045-W2F0-0
1 x DR55
22 / 50 100.7 79.5 78.0 69.4 60.3 60.3 48.6 48.6 62.0 62.0
24 / 45 114.1 91.2 91.4 81.1 72.4 72.4 61.0 61.0 79.5 76.0
26 / 40 126.0 103.0 103.1 92.9 84.3 84.3 73.1 73.1 91.3 84.7
SC25D050-W2F0-0
1 x DR70
22 / 50 109.2 86.9 84.2 75.8 65.8 65.8 53.0 53.0 67.8 67.8
24 / 45 123.8 99.7 98.8 88.7 79.0 79.0 66.5 66.5 84.5 80.3
26 / 40 136.7 112.6 111.6 101.6 92.0 92.0 79.8 79.8 98.9 93.5
SC25D055-W2F0-0
1 x DR70
22 / 50 117.2 94.0 90.1 82.1 71.1 71.1 57.3 57.3 73.4 73.4
24 / 45 132.9 107.9 105.8 96.0 85.4 85.4 71.9 71.9 90.6 87.8
26 / 40 147.0 122.0 119.7 110.1 99.6 99.6 86.3 86.3 106.1 102.2
SC25D067-W2F0-0
1 x DR95
22 / 50 117.2 94.0 90.1 82.1 71.1 71.1 57.3 57.3 73.4 73.4
24 / 45 132.9 107.9 105.8 96.0 85.4 85.4 71.9 71.9 90.6 87.8
26 / 40 147.0 122.0 119.7 110.1 99.6 99.6 86.3 86.3 106.1 102.2
SC25D073-W2F0-0
1 x DR95
22 / 50 117.2 94.0 90.1 82.1 71.1 71.1 57.3 57.3 73.4 73.4
24 / 45 132.9 107.9 105.8 96.0 85.4 85.4 71.9 71.9 90.6 87.8
26 / 40 147.0 122.0 119.7 110.1 99.6 99.6 86.3 86.3 106.1 102.2
SC25D080-W2F0-0
1 x DR95 (EC)
22 / 50 117.2 94.0 90.1 82.1 71.1 71.1 57.3 57.3 73.4 73.4
24 / 45 132.9 107.9 105.8 96.0 85.4 85.4 71.9 71.9 90.6 87.8
26 / 40 147.0 122.0 119.7 110.1 99.6 99.6 86.3 86.3 106.1 102.2
SC31D055-W2F0-0
1 x DR70
22 / 50 117.0 90.1 92.1 78.7 71.1 67.7 56.6 56.6 82.6 73.8
24 / 45 132.0 103.0 107.0 91.6 91.0 91.0 70.1 70.1 99.8 88.0
26 / 40 145.2 116.1 120.1 104.7 98.7 91.8 83.4 83.4 114.5 101.9
SC31D065-W2F0-0
1 x DR95
22 / 50 133.3 103.7 104.5 90.6 79.8 79.8 64.9 64.9 93.1 84.8
24 / 45 150.5 118.7 121.6 105.6 97.4 92.6 80.5 80.5 112.6 101.0
26 / 40 165.8 133.8 136.7 120.8 112.7 107.8 95.9 95.9 129.3 117.1
SC31D075-W2F0-0
1 x DR95
22 / 50 148.7 116.8 116.1 102.1 89.6 89.6 72.8 72.8 102.8 95.2
24 / 45 168.0 133.7 135.2 119.1 107.0 107.0 90.5 90.5 124.4 113.6
26 / 40 185.1 151.0 152.1 136.3 124.2 124.2 107.9 107.9 143.1 131.7
SC31D077-W2F0-0
1 x DR95
22 / 50 148.7 116.8 116.1 102.1 89.6 89.6 72.8 72.8 102.8 95.2
24 / 45 168.0 133.7 135.2 119.1 107.0 107.0 90.5 90.5 124.4 113.6
26 / 40 185.1 151.0 152.1 136.3 124.2 124.2 107.9 107.9 143.1 131.7
SC31D080-W2F0-0
1 x DR95 (EC)
22 / 50 148.7 116.8 116.1 102.1 89.6 89.6 72.8 72.8 102.8 95.2
24 / 45 168.0 133.7 135.2 119.1 107.0 107.0 90.5 90.5 124.4 113.6
26 / 40 185.1 151.0 152.1 136.3 124.2 124.2 107.9 107.9 143.1 131.7
SC31D083-W2F0-0
1 x DR95 (EC)
22 / 50 148.7 116.8 116.1 102.1 89.6 89.6 72.8 72.8 102.8 95.2
24 / 45 168.0 133.7 135.2 119.1 107.0 107.0 90.5 90.5 124.4 113.6
26 / 40 185.1 151.0 152.1 136.3 124.2 124.2 107.9 107.9 143.1 131.7
TC = Total Cooling, SC =Sensible Cooling, THR= Total Heat of Rejection
(1) All data quoted is gross, Capacities based on water ∆T stated. With Constant water flow systems the free cooling performance may be reduced if the flow
through the condenser is lower than required for the free cooling. Please contact Airedale for performance figures.
(2) Deduct fan gain for net duties, refer to Mechanical Data
(3) All data quoted is based upon 100% water.
W2F0
