AIREDALE SmartCool D - Chilled Water Single Circuit (C000) Performance Data; C000 Cooling Duties Performance Data

Precision Air Conditioning
SmartCool
TM
– D
Precision Air Conditioning
143
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Chilled Water Single Circuit (C000)
Performance Data – Chilled Water – Single Circuit
Cooling Duties
Water Inlet / Outlet Temperatures
Model Air On 5°C / 10°C 7°C / 12°C 8°C / 14°C 10°C / 16°C 5.5°C / 14.5°C
Temp (°C)/ %RH
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
SC19D065-C000-0
22 / 50 78.8 61.3 62.6 53.5 47.5 43.9 37.0 37.0 55.4 49.5
24 / 45 88.6 69.9 72.5 62.1 60.1 56.4 46.1 46.1 67.8 59.5
26 / 40 97.4 78.6 81.2 70.8 69.1 65.3 54.7 54.7 78.0 69.0
SC19D075-C000-0
22 / 50 88.9 69.6 70.5 60.7 53.8 50.4 42.0 42.0 62.7 56.4
24 / 45 100.1 79.4 81.7 70.6 67.5 64.1 52.3 52.3 76.4 67.5
26 / 40 110.1 89.4 91.6 80.6 77.8 74.2 62.2 62.2 87.9 78.3
SC19D090-C000-0
22 / 50 103.5 81.6 81.7 71.3 62.8 60.0 49.3 49.3 72.9 66.2
24 / 45 116.7 93.3 94.9 82.9 78.1 75.2 61.2 61.2 88.5 79.2
26 / 40 128.3 105.1 106.6 94.7 86.9 81.5 72.9 72.9 101.7 91.8
SC25D090-C000-0
22 / 50 111.3 87.5 87.8 76.3 66.4 64.2 51.9 51.9 74.0 70.3
24 / 45 125.5 100.0 102.1 88.9 80.2 74.7 65.2 65.2 92.0 83.6
26 / 40 138.2 112.7 114.7 101.5 92.8 86.6 77.9 77.9 107.3 97.6
SC25D100-C000-0
22 / 50 121.6 96.1 95.7 83.7 72.7 71.0 57.1 57.1 81.5 77.4
24 / 45 137.2 109.8 111.4 97.6 87.9 82.8 71.6 71.6 100.5 91.9
26 / 40 151.2 123.8 125.3 111.5 101.7 96.0 85.5 85.5 117.1 107.2
SC25D110-C000-0
22 / 50 131.6 104.4 103.4 91.0 78.7 77.7 62.1 62.1 88.6 84.3
24 / 45 148.7 119.5 120.5 106.2 95.3 90.7 77.8 77.8 108.8 99.9
26 / 40 163.7 134.7 135.5 121.4 110.4 105.4 93.0 93.0 126.4 116.6
SC31D110-C000-0
22 / 50 127.4 98.5 101.7 86.0 81.8 76.7 60.2 60.2 93.7 81.2
24 / 45 143.1 112.3 117.4 99.8 98.3 90.9 74.4 74.4 112.5 96.7
26 / 40 157.0 126.1 131.3 113.7 112.7 105.0 88.2 88.2 128.5 111.7
SC31D130-C000-0
22 / 50 146.8 114.3 116.9 99.8 93.8 88.9 69.8 69.8 107.7 94.2
24 / 45 165.1 130.3 135.2 115.9 112.8 105.5 86.3 86.3 129.1 112.0
26 / 40 181.3 146.5 151.3 132.1 129.3 122.0 102.4 102.4 147.4 129.5
SC31D150-C000-0
22 / 50 165.5 129.6 131.5 113.2 101.1 93.9 79.1 79.1 120.9 106.7
24 / 45 186.3 147.9 152.2 131.6 126.5 119.6 97.8 97.8 144.9 126.8
26 / 40 204.7 166.4 170.5 150.1 145.2 138.5 116.1 116.1 165.4 146.7
TC = Total Cooling, SC =Sensible Cooling
(1) All data quoted is gross
(2) Deduct fan gain for net duties, refer to Mechanical Data
(3) Water Flow rate (l/s)= TC/(4.19 x ∆T) at 100% Water
(4) Refer to Waterside pressure Drop (kPa)
C000
