Mechanical Data - C0C0 Continued
SC31D055-C0C0-0 SC31D065-C0C0-0 SC31D075-C0C0-0
Capacity
(1)
Nom Cooling (Gross) kW 79.1 87.0 94.6
Fan Gain kW 1.25 2.06 3.22
Dimensions - H x D x W
mm
3113 x 890 x 1980 3113 x 890 x 1980 3113 x 890 x 1980
Weight - Machine / Operating
kg 1010 / 1100 1010 / 1100 1010 / 1100
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black Grey (RAL 7021)
Material/Colour Frame:Anodised Aluminium Frame with Black Nylon Corners
Cooling Coil
Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages 1 (Modulated) / 1
Water volume L 87.9 87.9 87.9
Water flow rate l/s 3.79 4.27 4.71
Pressure drop kPa 33.13 36.25 39.40
Fan & Motor
Backwards Curved, Centrifugal direct drive
Motor Type EC EC EC
Quantity x Motor Size kW 3 x 3.1 3 x 3.1 3 x 3.1
Speed @25Pa ESP/ Maximum ESP Rpm 1061 / 1520 1261 / 1520 1479 / 1520
Maximum ESP Pa 528 330 77
Nominal Airflow m³/s 5.8 6.9 7.9
Connections
Water Inlet / Outlet mm 42 42 42
Condensate Drain Hose mm 22 22 22
Filtration Disposable to BS EN 779-G4-741
Quantity 4 4 4
OPTIONAL EXTRAS
Electric Heating (Total) kW 31.5 31.5 31.5
Humidifier
Capacity kg/hr 15 15 15
Feed/Drain ¾" BSPF Braided flexible hose / 19mm hose connection
Condensate Pump
Head m 10 10 10
Flow l/m 5 5 5
Drain
10mm Stainless Steel Stub Connection
Standard Fan Motor - EC Motor
Backwards Curved, Centrifugal direct drive
Quantity x Motor Size kW N/A N/A N/A
Speed @ 25Pa / Maximum ESP rpm N/A N/A N/A
Maximum ESP Pa N/A N/A N/A
Fan Gain kW N/A N/A N/A
Larger Fan Motor - EC Motor
Backwards Curved, Centrifugal direct drive
Quantity x Motor Size kW N/A N/A N/A
Speed @ 25Pa / Maximum ESP rpm N/A N/A N/A
Maximum ESP Pa N/A N/A N/A
Fan Gain kW N/A N/A N/A
Low Pressure Hot Water
(2)
Capacity Gross kW 39.8 42.7 45.2
Water Flow (Nominal) l/s 0.81 0.88 0.95
Pressure drop Kpa 35.9 37.4 38.8
LPHW Connection Sizes mm 22 22 22
(1) Entering air 24°C/ 45% RH water 7°C/ 12°C
(2) Based upon low pressure hot water 82°C inlet/71°C outlet. Air on 20°C
(3) Fan gain based on 25Pa ESP @ nominal air volume. Fan gain figure will change as airflow and ESP change.
