General Specification
Mechanical Data
–
Condensers and Dry Coolers
CR12 CR16 CR22 CR26 CR30
DR10 DR12 DR15
Total Heat of Rejection CR
(1) kW 14.1 18.6 24.6 30.7 31.3
Total Heat of Rejection DR
(2) kW N/A N/A 11.1 13.7 15.3
Dimensions - Horizontal
(3)
H x W x L mm
972 x 1000 x 907 972 x 1000 x 907 1167 x 1000 x 1102 1167 x 1000 x 1102 1167 x 1000 x 1102
Dimensions – Vertical
(3)
H x W x L mm
1076 x 972 x 907 1076 x 972 x 907 1090 x 1167 x 1102 1155 x 1000 x 1102 1090 x 1167 x 1102
Weight
Machine kg 62 70 77 93 90
Construction
Material/Colour Galvanised Sheet Steel, Epoxy Baked Powder Paint - Light Grey (RAL 7035)
Condenser
Air Cooled - Rifled Copper Tube/Turbulated Aluminium Fins
Dry Cooler
Air Cooled - Copper Tube/Turbulated Aluminium Fins
Total Face Area m² 0.58 0.58 0.91 0.91 0.91
Nominal Airflow m³/s 1.3 1.1 2.3 3.3 1.9
Discharge
-H Horizontal or -V Vertical (Please Specify at Order)
Fan & Motor
Axial
Quantity 1 1 1 1 1
Diameter mm 500 500 630 710 630
Maximum Speed rpm 910 910 895 930 895
Refrigeration - CR
Single Circuit
Refrigerant Type R410A
Holding Charge Inert Gas
Coil Volume l 3.0 6.0 4.7 4.7 9.3
Refrigerant Charge (4) kg 1.4 2.7 2.2 2.2 4.3
Dry Cooler
Internal Water Volume L 6.6 6.6 11.9
Nominal Flowrate l/s 0.53 0.65 0.7
Pressure Drop kPa 11.9 17.8 20.7
Connections
Liquid Line – Sweat in 5/8 5/8 5/8 5/8 3/4
Discharge Line – Sweat in 5/8 5/8 5/8 5/8 3/4
OPTIONAL EXTRAS
Short Case Axial Fan
Designed to 75 Pa ESP
Dimensions - Horizontal
H x W x L mm
972 x 1000 x 907 972 x 1000 x 907 1167 x 1000 x 1102 1167 x 1000 x 1102 1167 x 1000 x 1102
Dimensions - Vertical
H x W x L mm
1080 x 972 x 907 1080 x 972 x 907 1130 x 1167 x 1102 1140 x 1167 x 1102 1130 x 1167 x 1102
Weight
Machine kg 67 75 88 105 101
EC Fan
Dimensions - Horizontal
H x W x L mm
972 x 1000 x 907 972 x 1000 x 907 1167 x 1000 x 1102 1167 x 1000 x 1102 1167 x 1000 x 1102
Dimensions - Vertical
H x W x L mm
1065 x 972 x 907 1065 x 972 x 907 1127 x 1167 x 1102 1170 x 1167 x 1102 1127 x 1167 x 1102
Weight
Machine kg 67 76 83 90 96
(1) Nominal data based on 35°C ambient and a 50°C mean condensing temperature and using standard fan.
(2) Nominal data based on 35°C ambient and 45/40°C Water entering / leaving.
(3) Overall dimensions for clearance;.
(4) For guidance only.
