CR80 CR95 CR105
DR40 DR50 DR55
Total Heat of Rejection CR
(1) kW 87.8 110.9 113.2
Total Heat of Rejection DR
(2) kW 41.8 53 54.4
Dimensions - Horizontal
(3)
H x W x L mm
1167 x 1000 x 3565 1167 x 1000 x 3565 1167 x 1000 x 3565
Dimensions - Vertical
(3)
H x W x L mm
1090 x 1167 x 3565 1155 x 1167 x 3565 1090 x 1167 x 3565
Weight
Machine kg 208 258 260
Construction
Material/Colour Galvanised Sheet Steel, Epoxy Baked Powder Paint - Light Grey (RAL 7035)
Condenser
Air Cooled - Rifled Copper Tube/Turbulated Aluminium Fins
Dry Cooler
Air Cooled - Copper Tube/Turbulated Aluminium Fins
Total Face Area m² 3.63 3.63 3.63
Nominal Airflow m³/s 7.5 10.8 6.6
Discharge
-H Horizontal or -V Vertical (Please Specify at Order)
Fan & Motor
Axial
Quantity 3 3 3
Diameter mm 630 710 630
Maximum Speed rpm 895 930 895
Refrigeration - CR
Single Circuit
Refrigerant Type R410A
Holding Charge Inert Gas
Coil Volume l 18.3 18.3 36.6
Refrigerant Charge (4) kg 8.4 8.4 16.7
Dry Cooler
Internal Water Volume L 23.1 23.1 43.2
Water flowrate l/s 2.0 2.5 2.6
Pressure Drop kPa 48.5 70 32
Connections
Liquid Line - Sweat in 7/8 7/8 7/8
Discharge Line - Sweat in 1 3/8 1 3/8 1 3/8
OPTIONAL EXTRAS
Short Case Axial Fan
Designed to 75 Pa ESP
Dimensions - Horizontal
H x W x L mm
1167 x 1000 x 3565 1167 x 1000 x 3565 1167 x 1000 x 3565
Dimensions - Vertical
H x W x L mm
1130 x 1167 x 3565 1140 x 1167 x 3565 1130 x 1167 x 3565
Weight
Machine kg
242 249 294
EC Fan
Dimensions - Horizontal
H x W x L mm
1167 x 1000 x 3565 1167 x 1000 x 3565 1167 x 1000 x 3565
Dimensions - Vertical
H x W x L mm
1127 x 1167 x 3565 1170 x 1167 x 3565 1127 x 1167 x 3565
Weight
Machine kg 228 293 280
(1) Nominal data based on 35°C ambient and a 50°C mean condensing temperature and using standard fan.
(2) Nominal data based on 35°C ambient and a 45/40°C Water entering / leaving.
(3) Overall dimensions for clearance; refer to
Dimensional & Installation Data, for detail.
(4) For guidance only.
OUTDOOR
