Installation, Maintenance and Commissioning Manual :6877419 02/2013
Electrical Data
Condenser CR12 CR16 CR22 CR26 CR30 CR35 CR50 CR60 CR65
Dry Cooler DR10 DR12 DR15 DR20 DR25 DR30 DR35
Unit Data
(1)
Nominal Run Amps A 1.18 1.18 2.62 1.65 2.62 1.65 5.24 3.3 5.24
Maximum Start Amps A 4.13 4.13 9.17 6.1 9.17 6.1 18.34 12.2 18.34
Recommended Mains Fuse A 6 6 6 6 6 6 10 6 10
Max Mains Cable Incoming mm² 6 6 6 6 6 6 6 6 6
Mains Supply 50Hz 230V/1Ph 400V/3Ph 230V/1Ph 400V/3Ph 230V/1Ph 400V/3Ph 230V/1Ph
Fan - Per Fan
Quantity 1 1 1 1 1 1 2 2 2
Motor Size kW 0.27 0.27 0.6 0.88 0.6 0.88 0.6 0.88 0.6
Full Load Amps A 1.18 1.18 2.62 1.65 2.62 1.65 2.62 1.65 2.62
Locked Rotor Amps A 4.13 4.13 9.17 6.1 9.17 6.1 9.17 6.1 9.17
OPTIONAL EXTRAS
Short Case Axial Fan - Per Fan
Quantity 1 1 1 1 1 1 2 2 2
Motor Size kW 0.61 0.61 1.4 1.94 1.4 1.94 1.4 1.94 1.4
Full Load Amps A 2.8 2.8 6 3.4 6 3.4 6 3.4 6
Locked Rotor Amps A 7 7 18 11.9 18 11.9 18 11.9 18
EC Condenser Fan - Per Fan
Quantity 1 1 1 1 1 1 2 2 2
Motor Size kW 0.69 0.69 0.73 1.68 0.73 1.68 0.73 1.68 0.73
Full Load Amps A 3.1 3.1 3.3 2.6 3.3 2.6 3.3 2.6 3.3
Condenser CR75 CR80 CR95 CR105 CR130 CR140 CR165
Dry Cooler DR45 DR40 DR50 DR55 DR75 DR70 DR95
Unit Data
(1)
Nominal Run Amps A 3.3 7.86 4.95 7.86 4.95 10.48 6.6
Maximum Start Amps A 12.2 27.51 18.3 27.51 18.3 36.68 24.4
Recommended Mains Fuse A 6 16 10 16 10 16 10
Max Mains Cable Incoming
mm
² 6 6 6 6 6 6 6
Mains Supply 50Hz 400V/3Ph 230V/1Ph 400V/3Ph 230V/1Ph 400V/3Ph 230V/1Ph 400V/3Ph
Fan - Per Fan
Quantity 2 3 3 3 3 4 4
Motor Size kW 0.88 0.6 0.88 0.6 0.88 0.6 0.88
Full Load Amps A 1.65 2.62 1.65 2.62 1.65 2.62 1.65
Locked Rotor Amps A 6.1 9.17 6.1 9.17 6.1 9.17 6.1
OPTIONAL EXTRAS
Short Case Axial Fan - Per Fan
Quantity 2 3 3 3 3 4 4
Motor Size kW 1.94 1.4 1.94 1.4 1.94 1.4 1.94
Full Load Amps A 3.4 6 3.4 6 3.4 6 3.4
Locked Rotor Amps A 11.9 18 11.9 18 11.9 18 11.9
EC Condenser Fan - Per Fan
Quantity 2 3 3 3 3 4 4
Motor Size kW 1.68 0.73 1.68 0.73 1.68 0.73 1.68
Full Load Amps A 2.6 3.3 2.6 3.3 2.6 3.3 2.6
Interconnecting
Wiring
(CR26,35,60,75,95,130,165)
L1
¡ ç
Mains Incoming 400V / 3Ph + N / 50Hz
L2
¡ ç
L3
¡ ç
N
¡ ç
PE
¡ ç
Interconnecting wiring
(CR12,16,22,30,50,60,65,80,105,140)
L1
¡ ç
Mains Incoming 230V / 1Ph + N / 50HzN
¡ ç
PE
¡ ç
(1) Nominal data based on 35°C ambient and a 50°C mean condensing temperature and using standard fan.
OUTDOOR
