Model
Fan
Selection
Standard
Air Volume
(m³/s)
DeHum
Air
Volume
(m³/s)
Max Air
Volume
(m³/s)
External Static Pressure (Pa)
25
50
75
100
125
150
175
200
225
250
275
300
SC19D033-
W2C0-0
EC SC19D
STD
3.71 7.1 7.2 7.4 7.6 7.7 7.9 8.1 8.2 8.4 8.6 8.7 8.9
1.86 3.8 4.1 4.4 4.6 4.9 5.2 5.5 5.8 6.1 6.4 6.7 7.0
5.50 - - - - - - - - - - - -
EC SC19D
UPG
3.71 6.5 6.7 6.9 7.0 7.2 7.4 7.5 7.7 7.8 7.9 8.1 8.2
1.86 3.4 3.7 4.0 4.4 4.7 5.0 5.2 5.4 5.6 5.9 6.1 6.3
5.50 9.6 9.7 9.8 9.9 - - - - - - - -
SC19D038-
W2C0-0
EC SC19D
STD
4.27 8.0 8.2 8.3 8.5 8.6 8.8 8.9 9.1 9.2 9.4 9.5 9.7
2.14 4.2 4.5 4.8 5.0 5.3 5.6 5.9 6.2 6.4 6.7 7.0 7.2
5.50 - - - - - - - - - - - -
EC SC19D
UPG
4.27 7.6 7.7 7.8 8.0 8.1 8.2 8.4 8.5 8.6 8.7 8.9 9.0
2.14 3.7 4.1 4.4 4.7 5.0 5.2 5.5 5.7 5.9 6.1 6.3 6.5
5.50 9.6 9.7 9.8 9.9 - - - - - - - -
SC19D045-
W2C0-0
EC SC19D
STD
5.06 9.4 9.6 9.7 9.9 - - - - - - - -
2.53 4.8 5.1 5.4 5.6 5.9 6.1 6.4 6.7 6.9 7.2 7.3 7.5
5.50 - - - - - - - - - - - -
EC SC19D
UPG
5.06 8.9 9.0 9.1 9.2 9.4 9.5 9.6 9.7 9.8 9.9 - -
2.53 4.4 4.8 5.1 5.3 5.5 5.7 5.9 6.1 6.3 6.5 6.7 6.9
5.50 9.6 9.7 9.8 9.9 - - - - - - - -
SC19D064-
W2C0-0
EC SC19D
STD
5.06 9.4 9.6 9.7 9.9 - - - - - - - -
2.53 4.8 5.1 5.4 5.6 5.9 6.1 6.4 6.7 6.9 7.2 7.3 7.5
5.50 - - - - - - - - - - - -
EC SC19D
UPG
5.06 8.9 9.0 9.1 9.2 9.4 9.5 9.6 9.7 9.8 9.9 - -
2.53 4.4 4.8 5.1 5.3 5.5 5.7 5.9 6.1 6.3 6.5 6.7 6.9
5.50 9.6 9.7 9.8 9.9 - - - - - - - -
SC19D070-
W2C0-0
EC SC19D
STD
5.06 9.4 9.6 9.7 9.9 - - - - - - - -
2.53 4.8 5.1 5.4 5.6 5.9 6.1 6.4 6.7 6.9 7.2 7.3 7.5
5.50 - - - - - - - - - - - -
EC SC19D
UPG
5.06 8.9 9.0 9.1 9.2 9.4 9.5 9.6 9.7 9.8 9.9 - -
2.53 4.4 4.8 5.1 5.3 5.5 5.7 5.9 6.1 6.3 6.5 6.7 6.9
5.50 9.6 9.7 9.8 9.9 - - - - - - - -
SC19D076-
W2C0-0
EC SC19D
STD
5.06 9.4 9.6 9.7 9.9 - - - - - - - -
2.53 4.8 5.1 5.4 5.6 5.9 6.1 6.4 6.7 6.9 7.2 7.3 7.5
5.50 - - - - - - - - - - - -
EC SC19D
UPG
5.06 8.9 9.0 9.1 9.2 9.4 9.5 9.6 9.7 9.8 9.9 - -
2.53 4.4 4.8 5.1 5.3 5.5 5.7 5.9 6.1 6.3 6.5 6.7 6.9
5.50 9.6 9.7 9.8 9.9 - - - - - - - -
SC25D045-
W2C0-0
AC SC25D
STD
5.32 8.0 8.2 8.4 8.6 8.7 8.9 9.1 9.2 9.4 9.6 9.8 9.9
2.66 4.2 4.5 4.9 5.2 5.5 5.7 5.9 6.1 6.3 6.6 6.8 7.0
7.75 - - - - - - - - - - - -
EC SC25D
STD
5.32 7.5 7.7 7.8 8.0 8.2 8.3 8.5 8.7 8.8 9.0 9.2 9.3
2.66 4.0 4.3 4.6 4.9 5.2 5.5 5.8 6.1 6.4 6.7 7.0 7.2
7.75 - - - - - - - - - - - -
EC SC25D
UPG
5.32 7.0 7.1 7.3 7.4 7.6 7.7 7.9 8.0 8.2 8.3 8.5 8.6
2.66 3.7 4.0 4.3 4.6 4.9 5.2 5.4 5.6 5.8 6.0 6.3 6.5
7.75 9.9 - - - - - - - - - - -
SC25D050-
W2C0-0
AC SC25D
STD
5.91 8.8 9.0 9.2 9.3 9.5 9.7 9.8 - - - - -
2.96 4.6 5.0 5.3 5.5 5.8 6.0 6.2 6.4 6.7 6.9 7.1 7.3
7.75 - - - - - - - - - - - -
EC SC25D
STD
5.91 8.2 8.4 8.5 8.7 8.9 9.0 9.2 9.3 9.5 9.7 9.8 -
2.96 4.3 4.6 4.9 5.2 5.5 5.8 6.1 6.4 6.6 6.9 7.2 7.4
7.75 - - - - - - - - - - - -
EC SC25D
UPG
5.91 7.7 7.8 7.9 8.1 8.2 8.4 8.5 8.6 8.8 8.9 9.1 9.2
2.96 4.0 4.3 4.6 4.9 5.2 5.4 5.6 5.8 6.0 6.3 6.5 6.7
7.75 9.9 - - - - - - - - - - -
