AIREDALE SmartCool D - Air Cooled Models (X2 X2) Performance Data; X2 X2 Cooling Duties Performance

Precision Air Conditioning
SmartCool
TM
– D
Precision Air Conditioning
65
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Air Cooled Models (X2X2)
Performance Data – Air Cooled Models
Cooling Duties
Standard Condenser Match
X2X2 Ambient Temperature (°C)
Model Air On °C DB
25 30 35 40 46
%RH
TC
(KW)
SC
(KW)
TC
(KW)
SC
(KW)
TC
(KW)
SC
(KW)
TC
(KW)
SC
(KW)
TC
(KW)
SC
(KW)
SC19D055-X2X2-0
2 x CR50
22/50 52.4 48.8 52.4 48.8 51.7 48.5 49.1 47.4 45.7 45.7
24/45 53.5 52.4 53.5 52.4 52.8 52.0 50.2 50.2 46.7 46.7
26/40 54.5 54.5 54.5 54.5 53.7 53.7 51.1 51.1 47.6 47.6
SC19D070-X2X2-0
2 x CR65
22/50 65.2 59.8 65.2 59.8 64.9 59.6 62.2 58.4 58.7 56.9
24/45 66.9 64.2 66.9 64.2 66.5 64.1 63.7 63.0 60.1 60.1
26/40 68.3 68.3 68.3 68.3 67.9 67.9 65.0 65.0 61.4 61.4
SC19D080-X2X2-0
2 x CR65
22/50 74.2 67.2 74.2 67.2 73.1 66.7 69.8 65.3 65.7 63.5
24/45 76.1 72.2 76.1 72.2 74.9 71.6 71.5 70.2 67.3 67.3
26/40 77.7 77.6 77.7 77.5 76.3 76.3 72.9 72.9 68.7 68.7
SC25D080-X2X2-0
2 x CR65
22/50 75.7 69.8 75.7 69.8 74.4 69.2 71.1 67.5 66.9 65.4
24/45 77.6 75.1 77.6 75.1 76.2 74.4 72.8 72.7 68.5 68.5
26/40 79.3 79.3 79.3 79.3 77.7 77.7 74.3 74.3 70.0 70.0
SC25D090-X2X2-0
2 x CR65
22/50 82.4 76.5 82.4 76.5 80.4 75.6 76.8 73.8 72.1 71.6
24/45 84.6 82.3 84.6 82.3 82.3 81.2 78.6 78.6 73.9 73.9
26/40 86.4 86.4 86.4 86.4 84.0 84.0 80.2 80.2 75.5 75.5
SC25D100-X2X2-0
2 x CR80
22/50 93.9 85.6 93.9 85.6 92.1 84.6 88.0 82.6 82.8 80.0
24/45 96.3 91.7 96.3 91.7 94.3 90.7 90.1 88.7 84.8 84.8
26/40 98.3 98.3 98.3 98.3 96.1 96.1 91.9 91.9 86.5 86.5
SC31D100-X2X2-0
2 x CR80
22/50 95.8 86.2 95.8 86.2 93.6 85.2 89.3 83.1 83.7 80.4
24/45 98.3 92.5 98.3 92.5 95.9 91.4 91.5 89.4 85.8 85.8
26/40 100.3 99.3 100.3 99.3 97.8 97.8 93.3 93.3 87.7 87.7
SC31D120-X2X2-0
2 x CR105
22/50 109.6 99.1 109.6 99.1 109.0 98.8 104.1 96.5 97.9 93.6
24/45 112.4 106.4 112.4 106.4 111.6 106.0 106.7 103.9 100.4 100.4
26/40 114.8 114.4 114.8 114.4 113.9 113.9 108.9 108.9 102.5 102.5
SC31D130-X2X2-0
2 x CR105
22/50 117.2 105.7 117.2 105.7 115.9 105.1 110.9 102.8 104.5 99.9
24/45 120.2 113.4 120.2 113.4 118.7 112.7 113.6 110.5 107.0 107.0
26/40 122.8 122.1 122.8 122.1 121.2 121.2 116.0 116.0 109.3 109.3
TC=Total Cooling SC=Sensible Cooling
(1) All data quoted is gross
(2) Deduct fan gain for nett duties, refer to Mechanical Data
Technical
