AIREDALE SmartCool D - Indoor Unit Specifiers Guide; Indoor Unit Nomenclature

Precision Air Conditioning
SmartCool
TM
– D
Precision Air Conditioning
7
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Specifier’s Guide Indoor Unit
Nomenclature
International Example
è
SC19D065 - C000 -0
SC
19
D
065
-
C
0
0
0
-
0
Dual Cool Example
è
SC31D065 - X2C0 -0
SC
31
D
065
-
X
2
C
0
-
0
Mono Cool Example
è
SC25D100 - X2X2 -0
SC
25
D
100
-
X
2
X
2
-
0
SmartCool SC
Decimetre Case Width (dm)
19 - 31
Upflow U
Downflow D
Nominal Capacity (kW) 033-150
Separator -
Air Cooled (Comp Indoor) X
Water Cooled (Comp Indoor) W
Chilled Water C
No Compressor 0
Single Compressor 1
Tandem Compressor 2
Inverter Compressor V
No Option 0
Air Cooled (Comp Indoor) X
Water Cooled (Comp Indoor) W
Free Cooling F
Chilled Water C
No Compressor 0
Single Compressor 1
Tandem Compressor 2
Inverter Compressor V
Seperator -
400V 3PH 50Hz 0
Note
Dual Cool units are defined as those having 2 different cooling mediums (i.e. R410A and Chilled Water [X2C0]).
Dual Circuit units are defined as those having 2 independent cooling circuits (i.e. X2X2 or C0C0).
M o n o / D u a l
( C i r c u i t 1 )
M o n o / D u a l
( C i r c u i t 2 )
V o l t a g e
General
