Installation, Maintenance and Commissioning Manual :6877419 02/2013
Air Cooled and Chilled Water Models (X2C0)
Performance Data – Air Cooled & Chilled Water Models
Cooling Duties
X2C0 Ambient Temperature (°C)
Model Air On
25 30 35 40 46
Temp. (°C)
/ %RH
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
SC19D033-X2C0-0
1 x CR50
22 / 50 28.4 28.4 28.4 28.4 27.9 27.9 26.6 26.6 24.9 24.9
24 / 45 29.4 29.4 29.4 29.4 28.9 28.9 27.6 27.6 25.8 25.8
26 / 40 30.5 30.5 30.5 30.5 29.9 29.9 28.5 28.5 26.8 26.8
SC19D038-X2C0-0
1 x CR65
22 / 50 35.4 35.4 35.4 35.4 35.1 35.1 33.5 33.5 31.6 31.6
24 / 45 36.8 36.8 36.8 36.8 36.4 36.4 34.9 34.9 33.0 33.0
26 / 40 38.4 38.4 38.4 38.4 37.9 37.9 36.3 36.3 34.5 34.5
SC19D045-X2C0-0
1 x CR65
22 / 50 40.7 40.7 40.7 40.7 39.8 39.8 38.0 38.0 35.7 35.7
24 / 45 42.3 42.3 42.3 42.3 41.3 41.3 39.5 39.5 37.3 37.3
26 / 40 44.2 44.2 44.2 44.2 43.0 43.0 41.2 41.2 39.0 39.0
SC19D064-X2C0-0
1 x CR105
22 / 50 61.7 59.5 61.7 59.5 60.7 59.1 58.1 58.1 54.4 54.4
24 / 45 63.2 63.2 63.2 63.2 62.2 62.2 59.5 59.5 55.8 55.8
26 / 40 64.6 64.6 64.6 64.6 63.4 63.4 60.7 60.7 57.2 57.2
SC19D070-X2C0-0
1 x CR105
22 / 50 67.2 61.6 67.2 61.6 65.6 60.9 62.5 59.8 58.6 58.3
24 / 45 68.9 66.2 68.9 66.2 67.1 65.5 64.0 64.0 60.0 60.0
26 / 40 70.4 70.4 70.4 70.4 68.5 68.5 65.3 65.3 61.2 61.2
SC19D076-X2C0-0
1 x CR105
22 / 50 74.0 64.8 74.0 64.8 71.3 63.4 67.6 61.7 62.7 59.9
24 / 45 75.9 69.3 75.9 69.3 72.9 67.8 69.2 66.3 64.2 64.2
26 / 40 77.5 74.3 77.5 74.3 74.4 72.9 70.5 70.5 65.4 65.4
SC25D045-X2C0-0
1 x CR65
22 / 50 42.1 42.1 42.1 42.1 41.0 41.0 39.0 39.0 36.8 36.8
24 / 45 43.8 43.8 43.8 43.8 42.6 42.6 40.7 40.7 38.4 38.4
26 / 40 45.7 45.7 45.7 45.7 44.4 44.4 42.5 42.5 40.1 40.1
SC25D050-X2C0-0
1 x CR65
22 / 50 46.0 46.0 46.0 46.0 44.3 44.3 42.2 42.2 39.7 39.7
24 / 45 47.8 47.8 47.8 47.8 46.1 46.1 44.1 44.1 41.5 41.5
26 / 40 50.0 50.0 50.0 50.0 48.1 48.1 46.0 46.0 43.4 43.4
SC25D055-X2C0-0
1 x CR80
22 / 50 52.9 52.9 52.9 52.9 51.3 51.3 48.8 48.8 45.7 45.7
24 / 45 54.6 54.6 54.6 54.6 53.0 53.0 50.7 50.7 47.7 47.7
26 / 40 57.1 57.1 57.1 57.1 55.2 55.2 52.8 52.8 49.8 49.8
SC25D067-X2C0-0
1 x CR105
22 / 50 65.5 65.5 65.5 65.5 64.2 64.2 61.3 61.3 57.6 57.6
24 / 45 67.0 67.0 67.0 67.0 65.6 65.6 62.6 62.6 58.8 58.8
26 / 40 68.9 68.9 68.9 68.9 67.3 67.3 64.4 64.4 61.1 61.1
SC25D073-X2C0-0
1 x CR105
22 / 50 71.7 71.3 71.7 71.3 69.6 69.6 66.2 66.2 61.9 61.9
24 / 45 73.5 73.5 73.5 73.5 71.2 71.2 67.7 67.7 63.2 63.2
26 / 40 75.2 75.2 75.2 75.2 72.8 72.8 69.4 69.4 65.0 65.0
SC25D080-X2C0-0
1 x CR105
22 / 50 79.2 74.6 79.2 74.6 75.7 72.9 71.7 71.2 66.3 66.3
24 / 45 81.2 80.4 81.2 80.4 77.4 77.4 73.3 73.3 67.7 67.7
26 / 40 82.9 82.9 82.8 82.8 79.0 79.0 74.8 74.8 69.4 69.4
SC31D055-X2C0-0
1 x CR80
22 / 50 52.7 52.7 52.7 52.7 51.0 51.0 48.4 48.4 45.2 45.2
24 / 45 54.5 54.5 54.5 54.5 52.7 52.7 50.2 50.2 47.1 47.1
26 / 40 56.1 56.1 56.1 56.1 54.4 54.4 52.1 52.1 49.2 49.2
SC31D065-X2C0-0
1 x CR105
22 / 50 60.1 60.1 60.1 60.1 59.4 59.4 56.6 56.6 53.0 53.0
24 / 45 61.8 61.8 61.8 61.8 61.0 61.0 58.4 58.4 55.1 55.1
26 / 40 64.2 64.2 64.2 64.2 63.3 63.3 60.7 60.7 57.5 57.5
SC31D075-X2C0-0
1 x CR105
22 / 50 64.8 64.8 64.8 64.8 63.7 63.7 60.8 60.8 57.2 57.2
24 / 45 66.9 66.9 66.9 66.9 65.7 65.7 63.0 63.0 59.6 59.6
26 / 40 69.8 69.8 69.8 69.8 68.4 68.4 65.7 65.7 62.1 62.1
SC31D077-X2C0-0
1 x CR105
22 / 50 74.6 74.6 74.6 74.6 72.2 72.2 68.8 68.8 64.3 64.3
24 / 45 76.5 76.5 76.5 76.5 73.8 73.8 70.3 70.3 66.3 66.3
26 / 40 79.0 79.0 79.0 79.0 76.3 76.3 73.2 73.2 69.0 69.0
SC31D080-X2C0-0
1 x CR105
22 / 50 78.8 78.8 78.8 78.8 75.4 75.4 71.2 71.2 65.9 65.9
24 / 45 80.7 80.7 80.7 80.7 77.0 77.0 72.8 72.8 67.6 67.6
26 / 40 83.1 83.1 83.0 83.0 79.3 79.3 75.4 75.4 70.4 70.4
SC31D083-X2C0-0
1 x CR105
22 / 50 82.6 82.6 82.5 82.5 78.5 78.5 74.3 74.3 68.7 68.7
24 / 45 84.7 84.7 84.3 84.3 80.3 80.3 75.9 75.9 70.2 70.2
26 / 40 86.8 86.8 86.2 86.2 82.4 82.4 78.2 78.2 73.0 73.0
TC=Total Cooling SC=Sensible Cooling
(1) All data quoted is gross
(2) Deduct fan gain for nett duties, refer to Mechanical Data
X2C0
