Electrical Data – X2C0 Continued
SC25D045-X2C0-0 SC25D050-X2C0-0 SC25D055-X2C0-0
Standard Condenser Match 1 x CR65 1 x CR65 1 x CR80
Unit Data - X2C0
Nominal Run Amps A 64.8 64.4 82.2
Maximum Start Amps A 151.6 143.6 175.9
Recommended Mains Fuse Size A 80 100 100
Max Mains Incoming Cable Size mm² 35 35 35
Mains Supply V 400V / 3PH + N / 50Hz
Control circuit VAC 24 24 24
Unit Data Cooling Only X2C0
Nominal Run Amps A 47.8 47.5 54.2
Maximum Start Amps A 134.5 126.6 167.2
Recommended Mains Fuse Size A 63 63 63
Evaporator Fan Motor - Per Fan
Motor Type AC AC AC
Quantity x Motor Size kW 3 x 2.38 3 x 2.38 3 x 2.38
Full Load Amps A 5 5 5
Locked Rotor Amps A 17.5 17.5 17.5
Compressor 1 , Circuit 1
Motor Size kW 6.31 7.19 7.19
Nominal Run Amps A 13.27 12.87 12.87
Locked Rotor Amps A 100 92 92
Type of Start Direct On Line
Compressor 2, Circuit 1
Motor Size kW 6.31 7.19 9.46
Nominal Run Amps A 13.27 12.87 16.93
Locked Rotor Amps A 100 92 130
Type of Start Direct On Line
Standard Condenser Match - AC Motor Per Fan
Quantity x Motor Size kW 2 x 0.6 2 x 0.6 3 x 0.6
Full Load Amps A 2.62 2.62 2.62
OPTIONAL EXTRAS
Electric Heating
Number of stage of Reheat 2 2 3
Number of Elements 6 6 9
Rating (Total) kW 21 21 31.5
Current Per Phase A 30.31 30.31 45.47
Humidifier
Capacity kg/hr 8 8 8
Rating kW 6 6 6
Full Load Amps A 8.67 8.67 8.67
First upgrade Fan Motor - EC Motor - Per
Fan
Quantity x Motor Size kW 2 x 2.2 2 x 2.2 3 x 2.2
Full Load Amps A 3.3 3.3 3.3
Locked Rotor Amps A 3.3 3.3 3.3
Second upgrade Motor - EC Motor - Per Fan
Quantity x Motor Size kW 2 x 3.1 2 x 3.1 3 x 3.1
Full Load Amps A 4.8 4.8 4.8
Locked Rotor Amps A 4.8 4.8 4.8
Standard Condenser Match - EC Motor-Per Fan
Quantity x Motor Size kW 2 x 0.73 2 x 0.73 3 x 0.73
Full Load Amps A 3.3 3.3 3.3
Condenser Match - SCAF Fan
Quantity x Motor Size kW 2 x 1.4 2 x 1.4 3 x 1.4
Full Load Amps A 6 6 6
(1) Values given for function units with standard selections for heating, humidification, supply air fans and matched condenser
at 7°C evaporating and 54.4°C condensing
(2) Stated motor power is based on maximum electrical power absorbed
(3) Values are per compressor
