System Configurations
Dual Circuit
X2X2
The SmartCool X2X2 is an air cooled, direct
expansion (DX), double circuit system linked
to two separate, remotely mounted air cooled
condensers.
Optimised for heat transfer using energy
efficient refrigerant R410A in each circuit, the
X2X2 system is located within the conditioned
space, absorbing room heat and transferring it
outside to the condensers.
By using one or more same/dissimilar sized
scroll compressors across the X2X2 double
circuit, part load efficiency can be maximised
and capacity more precisely matched to
application.
W2W2
Suitable for applications favouring reduced
refrigerant charges, the SmartCool W2W2 is a
double circuit system featuring, DX cooling
within the case and dry coolers outside.
Warm room air is passed through two
completely independent evaporator coils and
an integral plate condenser transfers the heat
load to the glycol solution which is then
channelled outside to two air cooled dry
coolers.
General
