Electrical Data – W2W2 Continued
SC25D080-W2W2 SC25D090-W2W2 SC25D100-W2W2
Standard Dry Cooler Match 2 x DR55 2 x DR70 2 x DR70
Unit Data Full Function – W2W2
(1)
Nominal Run Amps A 93.1 95.2 103.3
Maximum Start Amps A 179.9 174.3 216.4
Recommended Mains Fuse Size A 125 125 125
Max Mains Incoming Cable Size mm² 70 70 70
Mains Supply V 400V / 3PH + N / 50Hz
Control circuit VAC 24 24 24
Unit Data Cooling Only – W2W2
Nominal Run Amps A 76.9 79 87.2
Maximum Start Amps A 163.7 158.1 200.2
Recommended Mains Fuse Size A 100 100 100
Evaporator Fan Motor – Per Fan
Motor Type AC AC AC
Quantity x Motor Size (2) kW 3 x 2.38 3 x 2.38 3 x 2.38
Full Load Amps A 5 5 5
Locked Rotor Amps A 17.5 17.5 17.5
Compressor – Compressor 1 , Circuit 1 & 2
(3)
Motor Size kW 6.31 7.19 7.19
Nominal Run Amps A 13.3 12.9 12.9
Locked Rotor Amps A 100 92 92
Type of Start Direct On Line
Compressor – Compressor 2, Circuit 1 & 2
(3)
Motor Size kW 6.31 7.19 9.46
Nominal Run Amps A 13.3 12.9 16.9
Locked Rotor Amps A 100 92 130
Type of Start Direct On Line
Standard Dry Cooler Match – AC Motor Per Fan
Quantity x Motor Size kW 3 x 0.6 4 x 0.6 4 x 0.6
Full Load Amps A 2.62 2.62 2.62
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat 2 3 2
Number of Elements 6 9 6
Rating (Total) kW 21 31.5 21
Current Per Phase A 30.31 30.31 45.47
Humidifier
Capacity kg/hr 15 15 15
Rating kW 11.25 11.25 11.25
Full Load Amps A 16.2 16.2 16.2
Standard Size Fan Motor – EC Motor – Per Fan
Quantity x Motor Size kW 3 x 2.2 3 x 2.2 3 x 2.2
Full Load Amps A 3.3 3.3 3.3
Locked Rotor Amps A 3.3 3.3 3.3
Larger Size Motor – EC Motor – Per Fan
Quantity x Motor Size kW 3 x 3.1 3 x 3.1 3 x 3.1
Full Load Amps A 4.8 4.8 4.8
Locked Rotor Amps A 4.8 4.8 4.8
Standard Condenser Match – EC Motor-Per Fan
Quantity x Motor Size kW 3 x 0.73 4 x 0.73 4 x 0.73
Full Load Amps A 3.3 3.3 3.3
SCAF Condenser Match – Motor- Per Fan
Quantity x Motor Size kW 3 x 1.4 4 x 1.4 4 x 4.1
Full Load Amps A 6 6 6
(1) Values given for full function units with standard selections for heating, humidification, supply air fans and matched condenser
at 7°C evaporating and 54.4°C condensing
(2) Stated motor power is based on maximum electrical power absorbed
(3) Values are per compressor
W2W2
