1.5 BS PLUG WIRING INSTRUCTIONS
Wiring Instructions: Should it be necessary to change the plug please note the wires in the mains
lead are coloured in accordance with the following code :
BLUE - NEUTRAL
BROWN - LIVE
GREEN AND YELLOW - EARTH
BLUE NEUTRAL N
BLACK
BROWN LIVE L
RED.
GREEN/YELLOW EARTH
E GREEN OR GREEN/YELLOW
13A (BS 1363) 13A
Wiring for a 13 Amp Plug (BS1363)
E
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows:
1. The wire is the and must be connected to the terminal which is marked with the letter
or coloured .
2. The wire is the and must be connected to the terminal which is marked with the letter or
coloured
3. The is the and must be connected to the terminal which is marked with the
letter or or coloured .
4. Always ensure that the cord grip is positioned and fastened correctly.
If a fused plug is used it must be fitted with a fuse.
If in doubt consult a qualified electrician.
Please note.
The Earth Terminal is marked with the letter or Earth Symbol .
Earth-
(Green/Yellow)
Neutral - N
(Blue)
Live - L
(Brown)
13 AMP
