AIRMAC DB40 - DB Version Series 40 Parts List; Exploded View Diagram; Component Identification

DB version series 40
NO. DESCRIPTION QTY
1
TOP SCREW 1
2
FILTER COVER 1
3
FOAM SEAL 1
4
FILT
ER 1
5
UPPER HOUSING 1
6
THERM
A
L PROTECTOR 1
7
ELECTROMAGNET 2
8
WIRE STOPPER 1
9
U-SHAPED COIL FRAME 1
10
L
–
TUBE 2
11
VIBRATION CONTROL RUBBER 4
12
A
CTIVATING ARM 1
13
DIAPHRAGM FRAME 2
14
DIAPHRAGM 2
15
U NUT 2
16
DIAPHRAGM HOUSING 2
17
CHECK VALVE 4
18
CHAMBER SEAL
(
ROUND
)
2
19
CHAMBER SEAL
(
OVAL
)
2
20
SIDE COVER
(
STEEL
)
2
21
POWER CORD 1
22
STEEL PLATE 1
23
GASKET 1
24
LOWER HOUSING 1
25
RUBBER FEET 4
