Fixing the Plug-in stand on transmitter
2.Push upward.
3.Pull stand
off back plastic
housing.
1.Insert “ " head
screw-driver
into position
shown above.
4.Hold the stand with hand,
press it vertically against
the “groove” originally
is to store the stand.
5.Glide the “stand”
downward.
Make sure
the “stand”
faces to
correct
direction.
6.The stand is now fixed.
Pressing “stand” downward,
as shown in picture above, can
take it off from back housing.
If there is another user nearby,
e.g. in the next house, installs the
same RV-0356 unit, your receiver
may be fault triggered by his/her
transmitter. You may select a
different RF address code to prevent
this. Receiver can only response
to RF coding with the same
address code setting as its
own address code.
with the same arrangement.
Position both Transmitter and
Receiver DIP-Switches
RF Address Code Setting
Replacing batteries in Transmitter
Flip to open the flap on
front plastic housing.
Upper compartment
2 x 1.5V AAA for powering
transmitter.
Lower compartment ,
2 x 1.5V AAA for backlit.
Internal setting (adjustable to users)
There are 6 setting are designed to be adjustable to users
for required applications. Before start programming this
transmitter thermostat, it’s necessary to complete
selecting these 6 settings.
Follow procedure description below;
Pressing and hold for 6 seconds to enter
setting selection mode. And to follow flashing Digits or
Symbols on LCD to complete following settings.
3.Repeating procedure of “pressing for next
setting and then pressing or buttons to select
preferred setting, to complete rest of internal settings;
Month,Day and YEAR
Hour and Minute
(Hysteresis)
-- Counting the time that the
transmitter has been in used.
smallest time counting unit: 100 hours
4.Press after adjustable internal setting completed,
and start programming transmitter thermostat.
Date--
Clock--
Switching differential
Filter (Service interval)
1. Press or to choose F or C setting.
2.Press to enter next setting( 24H/12H selection)
after C/ F selection complete. Continuing to use
or buttons to choose.
C/ F:
To Next Page
