Central Terminal Level Control Unit
Operators Manual
GSI 002
605-0000-428
Issue 1.2. Date 5/11/98
Page 8 of 14
6.2. Shelf Selection Menu
This menu is used to select the shelf, of which the LCU operation and
configuration information needs to be displayed and set respectively. Once the
shelf has been selected all the subsequent menus display the current shelf
identifier.
Select a Shelf 0--
1-T
>Shlf 1< Shlf 2 0--
Shlf 3 Shlf 4 0--
6.3. Status/Configuration/Version Selection Menu
SH: 3 0--
0--
Configure 0--
>Status< Ver ---
6.4. LCU Status Selection Menu
This menu allows selection between the four information screens
SH: 2 1-R
0--
>Link< Config 0--
Loop Error 0--
