AirTech L12 - Page 39

DESCRIPTIONS
Description
L305
Qty
Pos. No.
Description
L305
Qty
Pos. No.
Description
L305
Qty
Pos. No.
Description
L305
Qty
Cylinder
1
159-2
Exhaust valve washer
4
265
Allen bolt
4
450
Float
1
Rotor
1
159-3
Exhaust valve spring
4
266
Spring Lock washer
4
451
Nozzle Assembly
1
Sleeve, Bearing
4
159-4
Exhaust valve plate
4
300
Motor mounting bracket
1
451.1
O-Ring for Nozzle Assembly
1
Vane
3
159-5
Exhaust valve lock nut
4
301
Stud
3
452
Bolt
2
A-End plate
1
159-6
Exhaust valve seat plate
4
302
Spring Lock washer
3
453
Bolt for banjo fitting
1
B-End plate
1
163
Allen bolt
2
303
Hex nut
3
454
Banjo fitting
1
Bearing
2
164
Sealing ring
2
310
Coupling set (310 ~313)
1
454S
Sealing ring for 454
2
Shaft seal
2
168
O-Ring, Valve cover plate
1
311
Coupling Half, Pump Side
1
455
Oil Return tube
1
O-Ring, End plate
2
169
Valve cover plate
1
312
Connection Bolt with rubber boot
6
456
Elbow hydraulic fitting
1
Hexagon head screw
9
176
Hex nut
1
312.3
Rubber Boot
6
470*
BSLM hydraulic fitting
1
Spring Lock washer
9
177
Stud bolt
1
313
Coupling Half, Motor Side
1
470S*-1
Sealing ring for 470
1
Taper Pin
4
185
Gasket, Cylinder
1
314
Hexagon head screw for 50322B
10
470S*-2
Sealing ring for 470
1
A-Shaft key
1
186
Allen bolt
5
316
Set screw (Pump side)
2
471*
Oil tube(C)
1
B-Shaft key
1
187
Spring Lock washer
5
317
Set screw ( Motor side)
2
473*
Fitting
1
Oil sump
1
189
Stud
2
320
Spacer for fan
1
474*
Gas ballast
1
Sheet metal baffle
1
190
Spring Lock washer
2
321
Pump shaft end fan
1
477*
Ball valve
1
Oil sight glass
1
191
Hex nut
2
322
Motor shaft end fan for IEC Motor
1
480*
Gas Ballast Kit
1
Gasket, Oil sight glass
1
205
Side cover plate
1
322
Motor shaft end fan for IEC/ NEMA Motor
1
490
Gasket Kit
1
Plug, Oil fill
1
206
Gasket, Side cover plate
1
325
Washer, Spring lock
1
500
Maintenance Kit
1
O-Ring, Oil fill plug
1
207
Allen bolt
12
326
Washer, plain
1
510
Conversion kit, L type
1
Plug, Oil drain
1
208
Sealing ring
12
327
Hexagon bolt
1
520
Conversion kit, N Type
1
O-Ring, Oil drain plug
1
219
Straight hydraulic fitting
2
341
Hexagon head screw
3
530
Conversion kit, NM Type
1
Threaded fitting
1
220
BLM hydraulic fitting
1
345
Fan Cover
1
540
Conversion Kit, F type (with GB Kit)
1
oil filter
1
221
BSLM hydraulic fitting
2
359
Allen Bolt
4
541
Conversion Kit, F type (w/o GB Kit)
1
Oil sump cover plate
1
221S-1
Sealing Ring for 221
2
360
Allen Bolt
4
550
Inlet Check Valve Kit
1
Gasket, Oil sump cover
1
221S-2
Sealing Ring for 221
2
390
Adapter for eye bolt
1
600
Motor (NEMA)
1
Allen bolt
4
222
BSLM Hydraulic fitting
1
391
Eye bolt
1
600.3
Motor Fan (NEMA)
1
Sealing ring
4
222S
Sealing Ring
2
392
Spring Lock washer
1
600.4
Motor Fan Cover (NEMA)
1
Filter bracket
1
223
Elbow hydraulic fitting
1
393
Hexagon head screw
1
601
Allen Bolt (NEMA)
4
Exhaust filter
4
224
BLM hydraulic fitting
1
400
Motor (IEC)-50Hz
1
602
Spring lock washer(NEMA)
4
O-Ring, Exhaust filter
4
230
Oil tube (A-1)
1
400
Motor (IEC)-60Hz
1
610
Motor Mounting Flange adapter (NEMA)
1
Filter spring
4
231
Oil tube (B-1)
1
400,3
Motor Fan (IEC)
1
612B
Coupling set (311 + 312 + 613), (NEMA)
1
Slotted cheese head screw
4
232
Oil tube (B-2)
1
400,4
Motor Fan Cover (IEC)
1
613B
Coupling half, Motor side (NEMA)
1
Gasket, Service cover
1
234
Oil tube (B-3)
1
401
Hexagon head screw
4
622
Motor Shaft End Fan for Nema motor
1
Sealing ring
2
240
Cooling spiral Coil
1
402
Spring Lock washer
4
623
Collar for fan(# 622), for NEMA motor
1
