1750
Radius
6750
Radius
1750
Radius
Regulation FIBA Basketball Court
Scale 1:150 @ A4
28000
15000
900415049004150900
2500 12001200
1200
1250 Radius
375 4225 2525
2990 5335
975 900 875 875 1775
400
5675
System Overhangs - Front face of the pole, to the front face of the Backboard
Airtime 554 - 3' or 914mm
Airtime 660 - 3' or 914mm
Airtime 672 - 4' or 1219mm
Airtime 872 - 5' or 1524mm
(554/660)
(672)
(872)
Allow a minimum clearance
of 500mm from the back of
the pole, to operate the actuator
Wall or fence
872
672
554/660
System Posts
1219
1524
914
4600 Free Throw Line
7125 Three Point Line
