REVISION LEVEL A - 09/09/15
DUCTING RATING GUIDE
43
8
DUCTING RATING GUIDE FOR D8LC
DESIGNATION COMPONENT RATING
(measurements in millimeters) 1-duct 2-duct
Heating air ducting with reduction hood 100 dia.
(heater rating 8)
1 Grille, 100 dia. 0.1 -
2 Flexible pipe, 100 dia., per m 1.0 0.25
- Pipe bend, 90°, of ex. pipe, 100 dia. 0.5 0.15
3 Connecting socket, metal, 100 dia. 0 0
4 Grille, painted, 100 dia. 1.8 0.1
- Grille, nickel-plated, 100 dia. 1.8 0.1
5 Silencer, 100 dia. 1.1 0.25
6 Connector socket, 100 dia. 0.5 0.1
7 Outlet grill (rotatable), 100 dia. 5.5 1.2
8 Grille, 90x100 dia.* 0 -
9 Regulating valve 100x100x100 dia. - 2.6
10 Flexible pipe, 90 dia., per m 3 0.8
11 Connecting socket, metal, 90 dia. 0 0
12 Outlet grill (rotatable) 90 dia. - 1.4
13 Y-pipe 100x100x100 dia. - 0.4
14 Reduction piece, 100 dia. - 74 dia. 6.1 -
15 Flexible pipe 75 dia. per m - 2
- Pipe bend, 90° of ex. pipe, 75 dia. - 1.1
16 Outlet grill (rotatable) 75 dia. - -
17 Connector socket, 75 dia. 0 0
18 Connecting socket, metal, 75 dia. - -
*Pos. 8 - if used as adapter 90x100 dia., cut out the mesh.
