Airwell HKD DCI Series User Manual

EXPLODED VIEW AND SPARE PART LIST
HKD DCI 75 Version - 2
No.
BOM Code
Part Name
Quantity
1
11201007000039
Room Temperature Sensor
1
2
15822000002956
Condenser Assembly
1
3
11201007000136
Temperature Sensor
1
4
12222000004186
Right clapboard assembly
1
5
12100701000015
Big Handle.
1
6
12122000007150
Water Collecting Cover
1
7
12222000000576
Chassis Assembly
1
8
12222000004382
Front panel
1
8.1
12122000A03617
Air outlet grille
1
10
12100105000003
Axial fan
1
11
11002015000041
Brushless DC Motor
1
12
12222000002047
Fan Motor Holder Subassembly
1
13
12222000001379
Components of left supporting panel
1
14
12222000002451
Top cover assembly
1
15
12222000002226
Separation plate
1
17
15422000001945
Gas Valve Assembly
1
17.1
15500204000021
Low Pressure Valve
1
17.2
15500216000028
4-way Valve
1
17.3
12222000002571
Installing plate for valves
1
18
15422000001395
Liquid valve Assembly
1
18.1
15500208000028
Liquid valve
1
19
11103020000034
Inverter Controlled Rotary Compressor
1
20
11201007000005
Discharge temperature sensor assembly
1
21
17222000A17889
Electronic control box assembly
1
21.2
17122000018690
Outdoor power board assembly
1
21.3
12122000006913
Installation board for E-parts
1
21.5
12222000001311
Electric Installing Box Subassembly
1
22
15500406000010
Brass Nut
1
22
15500406000016
Brass Nut
1
