EXPLODED VIEW AND SPARE PART LIST
HKD DCI 77 Version - 2
No.
BOM Code
Part Name
Quantity
1
11201007000039
Room Temperature Sensor
1
2
15822000003682
Condenser Assembly
1
3
11201007000069
Temperature Sensor
1
4
12222000001428
Parts fn Right Side Plate
1
4.1
12222000002259
Terminal Installing Plate
1
4.2
17400401000016
Wire holder
1
5
12100701000015
Big Handle.
1
6
12122000007150
Water Collecting Cover
1
7
12222000000711
Chassis Assembly
1
8
12222000004382
Front panel
1
8.1
12122000A03617
Air outlet grille
1
10
12100105000051
Axial fan
1
11
11002015000041
Brushless DC Motor
1
12
12222200001462
Fan Motor Holder Subassembly
1
13
12222000001379
Components of left supporting panel
1
14
12222000002451
Top cover assembly
1
15
12222200001146
Separator Assembly
1
16
17400306000053
Reactor
1
17
15422000004716
Gas Valve Assembly
1
17.1
15500204000058
Low Pressure Valve
1
17.2
15500216000026
4-way Valve
1
17.3
12222000002571
Installing plate for valves
1
18
15422000004893
High-Voltage valve Assembly
1
18.1
15500208000028
Liquid valve
1
19
11103020000006
Inverter Controlled Rotary Compressor
1
20
11201007000005
Discharge temperature sensor assembly
1
21
17222000A17929
Electronic control box assembly
1
21.1
12122000006856
Electric Installing Box Subassembly
1
21.2
17122000018899
Outdoor power board assembly
1
21.5
12222000001325
Electric Installing Box Subassembly
1
22
15500406000012
Brass Nut
1
22
15500406000016
Brass Nut
1
