Page 9
F
Raccordements
Centrale RCW2
L maxi = 1000 m
Nbre unité max. = 32
15 zones maxi.
Câble paire torsadé
entre 0.12 et 0.3 mm²
Unité 1 Unité 2 Unité 3
GND12 V RS485
GND12 V RS485 GND12 V RS485 GND12 V RS485
