CX-LFAV500
E Model
SERVICE MANUAL
MICRO HI-FI COMPONENT SYSTEM
Sony Corporation
Home Audio Company
Published by Sony Engineering Corporation
9-961-145-01
2003H1678-1
© 2003.08
CX-LFAV500 is the Amplifier, Video CD/CD player,
Tape Deck and Tuner section in XR-FAV500.
SPECIFICATIONS
Ver 1.0 2003. 08
Model Name Using Similar Mechanism NEW
CD
CD Mechanism Type CDM55A-30BD61S
Section
Base Unit Name BU-30BD61S
Optical Pick-up Name A-MAX.3
TAPE
Model Name Using Similar Mechanism CX-LFA500
Section
Tape Transport Mechanism Type CMAL1Z222B
TUNER
FM tuning range 87.5 MHz to 108 MHz
FM usable sensitivity (IHF) 16.8 dBf
FM antenna terminal 75 Ω (unbalanced)
AM tuning range 531 kHz to 1602 kHz (9 kHz step)
530 kHz to 1710 kHz (10 kHz)
AM usable sensitivity 350 µV/m
AM antenna Loop antenna
AMPLIFIER
Power output Rated: 16 W + 16 W(1 kHz, T.H.D.
1 %, 6 Ω)
Reference: 20 W + 20 W(1 kHz,
T.H.D. 10 %, 6 Ω)
Inputs AUX IN: 500 mV
MIC: 1.0 mV (10 kΩ)
Outputs SPEAKERS: 6 Ω or more
PHONES: 32 Ω or more
CASSETTE DECK
Track format 4 tracks, 2 channels stereo
Frequency response 100 Hz – 10000 Hz
Recording system AC bias
Heads Recording/playback × 1, erase × 1
CD PLAYER
Laser Semiconductor laser (λ = 780 nm)
Emission duration: continuous
D/A converter 1 bit dual
Signal-to-noise ratio 80 dB (1 kHz, 0 dB)
Wow and flutter Unmeasurable
Video data MPEG 1
Audio data MPEG 1, Layer 2 (VCD)
MPEG 1, Layer 3 (MP3-CD)
GENERAL
Power requirements 120 V/220 V/230-240 V AC
(Switchable), 50/60 Hz
Power consumption 55 W
Power consumption in standby mode
with ECO mode on: 0.3 W
with ECO mode off: 10 W
Dimensions (w/h/d) Approx. 190 × 250 × 284 mm
Mass Approx. 4.5 kg
Supplied accessories: FM antenna (1)
AM antenna (1)
Speaker cords (2)
Remote commander (1)
Video connecting cord (1)
Batteries (2)
Speaker pads (8)
Specifications and external appearance are subject to change
without notice.
