ELECTRICAL MAIN PARTS LIST
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
CD MOTOR C.B
M1 S0-M10-A09-700 MOTOR SLED ASSY
PIN3 S2-369-750-000 PLUG,6P
SW1 S4-S13-A01-600 SW,LEAF
CD C.B
REF. NO.
CD MECHANISM
KSM-213CDM DA11T3C
C207 1/50 0.047 M
C209 0.068 0.047 M
C210 0.018 0.15 M
C216 0.33 0.15 M
C219 0.15 M 0.33/50
C228 1P 3P
C231 15P 22P
C243 0.1 0.1 M
C282 2700P 3300P M
R202 120K 82K
R203,207 150K 150K
R204~206 120K 82K
R218 68K 220K
R219 22K 15K
R220 12K 15K
R221 47K 33K
R222 1.5K 2.7K
R223 47K 22K
R230 22K 10K
R231 4.7K 12K
R232 47K 0
R234 1K 1K
R239 10K 10K
R243 15K 22K
R244 3.9K 8.2K
R245 22K 5.6K
R253 6.8K 15K
R262~263 560K 270K
R276 39K 15K
MECHANICAL PARTS LIST 1 / 1
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
8 8Z-CD9-615-010 SPKR,70HM
ADD 8Z-CDK-004-010 KEY,EQ
ADD 88-CT6-206-010 CUSHION,CD
ADD 8Z-CDK-203-010 HLDR,EQ PWB
ADD 8Z-CDK-205-010 HLDR,REPEAT LED
ADD 8Z-CDK-206-010 HLDR,SENSER
ADD 87-641-096-410 UT1+3-10
ADD 87-641-095-410 UT1+3-8
ADD 87-641-100-410 UT1+3-16
ADD 87-641-104-410 UT1+3-30
ADD 87-264-096-410 V+3-10 CR
ADD 87-644-096-410 UT1+3-10 CR
ADD 87-581-033-410 UIT+2-4
ADD 87-481-073-410 VWS+2.6-6
ADD 87-571-033-410 VIT+2-4
ADD 87-661-095-410 VFT1+3-8
ADD 87-651-035-410 VT1+2-6
ADD 87-621-072-410 QT1+2.6-5
ADD 87-581-096-410 UIT+3-10
ADD 87-651-075-410 VT1+2.6-10
COLOR NAME TABLE
Basic color symbol Color Basic color symbol Color Basic color symbol Color
B Black C Cream D Orange
G Green H Gray L Blue
LT Transparent Blue N Gold P Pink
R Red S Silver ST Titan Silver
T Brown V Violet W White
WT Transparent White Y Yellow YT Transparent Yellow
LM Metallic Blue LL Light Blue GT Transparent Green
LD Dark Blue DT Transparent Orange GM Metallic Green
YM Metallic Yellow DM Metallic Orange PT Transparent Pink
LA Aqua Blue GL Light Green
