24. MINUTE BUTTON FOR PROJECTION UNIT
25. HOUR BUTTON FOR PROJECTION UNIT
26. TIME SET BUTTON FOR PROJECTION UNIT
27. FOCUS ADJUSTMENT FOR PROJECTION UNIT
28. PROJECTION ON/OFF BUTTON
29. PROJECTION UNIT
30. AUTO DIMMER SENSOR
POWER CONNECTION
Plug the AC power cord to a household outlet AC source. This unit is
equipped with a battery back up system, it requires a 3 x 3Volt CR2025
Flat Lithium battery (Not included). Insert the battery in the battery
compartment, making certain that the positive and negative (+ and -)
battery terminals are attached to the corresponding terminals on the
plate in the battery compartment. If an AC power failure occurs, the
clock automatically switches to the battery power supply, the clock and
timer memory continue running. When the AC power resumes, the clock
switches back to AC again.
GETTING STARTED
Press the reset button (17) locates on the back of unit after AC plug in.
- The unit will display full segment for 2 seconds, then it will enter the
normal mode.
- Display will lighten up.
1. TIME AND CALENDAR SETTING
A. Setting Time and Calendar Ð Press Mode Set button (1) in normal
mode and keep depress over 2 second to enter Time Set mode, after
enter the setting mode, press Mode Set button (1) to change the
mode cycle as follows :
Action (during data adjustment) :
- Press button (7) to adjust data backward
- Press button (8) to adjust data forward
- Keep depress or button for 2 second to enable auto forward
To Next Page
