2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 6 C5,14,19,71~73
2 CS106K1606X7R CCAP SMD 10uF/16V 10% 1206 X7R 4 C2,11~13
2 FCN1T1001602 FCN Down Touch ZIF SMD Pitch=1.0mm 16P 1 J1
2 IC74HC595 Integrated Circuit 1 U64
2 LDKPT-1608SYCK Liquid-emitting Diode Yellow SMD 0603 10 LED0~7,74,75
angle 120°
2 PC13A015 Top Left Front 2Layer FR-4 85*139MM 1 -
2 RS004710F03 RES 47ȍ 1% SMD 0603 3 R14,18,368
2 SWEVQ11L04M Switch Tact 4.3mm 160g Horizontal DIP 15 SW32~46
1 TWPC13A01601 FSR PCB Assembly 1 18
2 AL2-49-0070 Diode BAV70 8 D13~20
2 AL2-71-1324 IC LMV324 SOP-14 1 U41
2 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 4 C82,84,86,88
2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 7 C74,80,92,96~99
2 CS106K1606X7R CCAP SMD 10uF/16V 10% 1206 X7R 5 C4,6,10,20,100
2 CS561J5003NPO CCAP SMD 560pF/50V 5% 0603 NPO 4 C81,83,85,87
2 FCN1T1001602 FCN Down Touch ZIF SMD Pitch=1.0mm 16P 1 J2
2 FCN1T1002602 FCN Down Touch ZIF SMD Pitch=1.0mm 26P 1 J3
2 IC74HC595 Integrated Circuit 6 U13,17,18,24,27,42
2 LDJ1M1F1BB7R4S3 Liquid-emitting Diode Red/Green/Blue SMD 16 LED29~44
0603 angle 120°
2 PC13A016 FSR PCB 2Layer FR-4 123*123MM 1 -
2 RS004710F03 RES 47
ȍ 1% SMD 0603 6 R2,6,15~17,452
2 RS010K10F03 RES 10K 1% SMD 0603 4 R220,224,228,232
2 RS022110F03 RES 221ȍ 1% SMD 0603 32 R23,24,26,27,29,30,34,36,38,39,41,42,45
R46,48,49,51,52,54,55,57,58,60,61,66,67
R69,70,72,73,75,78
2 RS03K310F03 RES 3.3K 1% SMD 0603 4 R218,222,226,230
2 RS043210F03 RES 432ȍ 1% SMD 0603 16 R21,25,28,31,37,40,43,47,50,53,56,59
R63,68,71,74
2 RS047010F03 RES 470ȍ 1% SMD 0603 4 R219,223,227,231
2 RS04K710F03 RES 4.7K 1% SMD 0603 4 R221,225,229,233
1 TWPC13A01703 TOP Right Front PCB Assembly 1 28
2 PC13A017 Top Right Front 2Layer FR-4 394*135MM 1
2 TWPC13A017A01 TOP Right Front PCB Assembly 1
3 AA822524X IC SN74HC165PW 4 U1~4
3 AA822748X Diode BAV99 1 D3
3 AL0-09-0044 Variable Resistor 8 R8,9,12,22,32,44,65,91
3 AL0-09-0057 VR 10KB 8 R107~109,111,116~119
3 AL0-17-0470 RES Array 4X47 1/10W 0603 4 R204~207
3 AL0-17-8103 RES ARRAY 8X10K 4 R3,4,35,64
3 AL2-51-4401 Transistor 2N4401 NPN SOT-23 (Transistor 2 Q11,14
MMBT4401LT1 NPN SOT-23)
3 AL2-51-4403 Transistor 2N4403 PNP SOT-23 4 Q1,10,12,13
3 AL2-62-0004 IC 74AHC04 1 U22
3 AL2-73-4051 IC74HC4051 Single 8-Chan Mux 16P Soic 3 U9,10,11
3 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO 4 C63~65,91
3 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 3 C1,89,94
3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 53 C7~9,15~18,21,23~41,43~47,49~62,66~69
C90,93,95
3 CS106K1606X7R CCAP SMD 10uF/16V 10% 1206 X7R 6 C3,75~79
3 DIZDSMAJ10ASM Diode 11.5V 400W 23A 1 D21
3 ECS22616B Capacitor Electrolytic 22uF/16V B type SMD 1 C22
3 FCN1T1002602 FCN Down Touch ZIF SMD Pitch=1.0mm 26P 2 J4,18
3 FCN1T1003001 FCN Down Touch ZIF SMD Pitch=1.0mm 30P 1 J17
