LC200A Handheld L/C Meter
Features:
High speed microcontroller’s precision
computation
Measuring range
below 1uH and 1pF
Intellectually Shutdown in 5 minutes
Especially qualify in microwave manufacture and measuring
switching power supply transformer, filter inductance and so on.
LC200A has four measuring range position:
1. C range ........Capacitance (0.01pF-10uF)
2. L range ........Inductance (0.001uH-100mH)
3. Hi.L range ......Big inductance (0.001mH-100H)
4. Hi.C range ......Big capacitance (1uF-100mF)
All range position are automatic measuring ranges, it is easy to
operate. Specification is as follows:
1.
Technique data：
Item Parameter
0.01pF-1pF 5%
1pF-1uF 1%
Capacitance
Accuracy
1uF-10uF 5%
Min Capacitance Resolution（C Range）
0.01pF
0.001uH-1uH 5% Inductance
Accuracy
1uH-100mH 1%
Min Inductance Resolution（L Range）
0.001uH
Big Inductance 100mH-1H 1%
