ALAULM ULC-4327FTB-21 - Page 18

G
H
N
Step 5:Attach stiffener panel(G) to side panel(B) and left side panel(C)
using bolts(O).
NOTE:Please fully tighten all bolts at this time.
Step 6:Bolt(N) the metal foot(H) to the left and right side panels.
NOTE:Please fully tighten all bolts at this time.
H
G Ox1
M6x30
M6x15
x4
x4
N
x8
18
