OmniSwitch OS6860/OS6900/OS10K Troubleshooting Guide Part No.032996-00 Rev.A
AOS Release 7.X and 8.X January 2015
Alcatel-Lucent Page 127 of 148
19. Troubleshooting Power Over Ethernet
Power over Ethernet (PoE) feature allows PoE -capable/Powered Devices (PD) to be powered up (such as IP
phones, WLAN Access Points, IP cameras). The OmniSwitch supports the IEEE 802.3af and 802.3at
standards. IEEE 802.3af (PoE) standard supports up to 15.4W and IEEE 802.3at (PoE+) standard supports up
to 25.5W.
Models supported: OS6860-P24, OS6860-P48, OS6860E-P24, OS6860E-P48
The supported power supply on the OS6860 and OS6860E devices are indicated, as below:
OS6860-P24 uses OS6860-BPPH (Modular 600-W AC PoE power supply)
OS6860-P48 uses OS6860-BPPX (Modular 920-W AC PoE power supply)
OS6860E-P24 uses OS6860-BPPH (Modular 600-W AC PoE power supply)
Summary of the commands in this chapter is listed here:
____________________________________________________________________
show powersupply
show lanpower slot <chassis/slot>
show lanpower slot <chassis/slot> capacitor-detection
show lanpower slot <chassis/slot> class-detection
show lanpower slot <chassis/slot> priority-disconnect
show lanpower slot <chassis/slot> usage-threshold
____________________________________________________________________
19.1. Troubleshooting PoE on OmniSwitch on OS6860 and
OS6860E
Command to verify PoEstatus: show lanpower slot <chassis/slot>
Command to verify power supply: show powersupply
Below is an example:
-> show powersupply
Total PS
Chassis/PS Power Type Status Location
-----------+---------+--------+--------+-----------
1/1 920 AC UP Internal
Total 920
PoEP ower Status
Default behaviour: PoE is disabled by default
PoE status command:
-> show lanpower slot <chassis/slot>
Below is an example:
-> show lanpower slot 1/1
Port Maximum(mW) Actual Used(mW) Status Priority On/Off Class Type
----+-----------+---------------+-----------+---------+--------+-------+----------
1 30000 0 Searching Low ON *
